OPERATIONS
18
VXZ766
English
Adjusting the bass
(Gain, Frequency, Q-curve)
• This function cannot be adjusted when as follows:
“Pro Logic” is set to “ON”, the speaker system is
set to “5.1ch”, DVD/DTS-CD is being played.
• This adjustment can only be performed when the
Z-Enhancer Plus is set to “CUSTOM”.
1. Press the [A-M] button and select “BASS”.
2. Turn the [ROTARY] knob to adjust the bass.
• The factory default setting is “B”.
(Adjustment range: -6 to +8)
3. Move the [ ] / [ ] lever to select
“B”.
4. Turn the [ROTARY] knob to select the
frequency.
• The factory default setting is “B”.
(Adjustment 50/80/120 Hz)
5. Move the [ ] / [ ] lever to select
“B”.
6. Turn the [ROTARY] knob to select the
Q-curve.
• The factory default setting is “B”.
(Adjustment 1/1.25/1.5/2)
7. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the treble
(Gain, Frequency)
• This function cannot be adjusted when as follows:
“Pro Logic” is set to “ON”, the speaker system is
set to “5.1ch”, DVD/DTS-CD is being played.
• This adjustment can only be performed when the
Z-Enhancer Plus is set to “CUSTOM”.
1. Press the [A-M] button and select “TREBLE”.
2. Turn the [ROTARY] knob to adjust the treble.
• The factory default setting is “T ”.
(Adjustment range: -6 to +6)
3. Move the [ ] / [ ] lever to select
“T”.
4. Turn the [ROTARY] knob to select the
frequency.
• The factory default setting is “T ”.
(Adjustment 8 kHz/12 kHz)
5. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the balance
• This function cannot be adjusted when as follows:
“Pro Logic” is set to “ON”, the speaker system is
set to “5.1ch”, DVD/DTS-CD is being played.
1. Press the [A-M] button and select “BAL 0”.
2. Turn the [ROTARY] knob to adjust the
balance of the left and right speakers.
• The factory default setting is “BAL 0”. (Adjustment
range: L13 to R13)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
Adjusting the fader
• This function cannot be adjusted when as follows:
“Pro Logic” is set to “ON”, the speaker system is
set to “5.1ch”, DVD/DTS-CD is being played.
1. Press the [A-M] button and select “FAD 0”.
2. Turn the [ROTARY] knob to adjust the
balance of the front and rear speakers.
• The factory default setting is “FAD 0”. (Adjustment
range: F12 to R12)
3. When the adjustment is complete, press the
[A-M] button several times until the function
mode is reached.
