2) Unload the two side panels see Figure 2.
3) Place cabinet onto under-frame and secure with bolts. Bolts are in the cabinet work zone
bag.Make the connection between the under frame and cabinet body (sees Figure 3), and
then mount side panels;
FIGURE 3: CONNECTION OF BASE AND CABINET BODY
1. RIGHT PANEL
8
2. CABINET
BODY
