3
ROOF MOUNTED
LINT DROPPED
TO LAUNDRY
FLOOR
D
• Installer must supply roof curb to support the 1,500 lb. filter.
• Guy wires may be required for additional support from high winds.
• Duct to the laundry floor for lint collection in 55 gallon drum with
Energenics supplied flexible connector.
• Controls and air and water valves must be mounted inside. Controls at
shoulder level, valves near the ceiling and roof penetration.
• Energenics optional side discharge or installer supplied gooseneck should
by mounted on the fan discharge and faced away from the prevailing
winds.
ROOF MOUNTED
LINT COLLECTED
UNDER THE FILTER
ON THE ROOF
E
• Least satisfactory method of installing. The 55 gallon drum may fill in 2
hours and must be emptied regularly or the unit clogs and produces high
back pressure.
• Requires installer supplied roof curb and guy wires. The filter with lint
drum underneath stands 30 inches higher than a normal roof mount with
the lint drum inside on the floor.
• Controls and air and water valves must be mounted inside. Controls at
shoulder level, valves near the ceiling and roof penetration.
• Energenics optional side discharge or installer supplied gooseneck should
by mounted on the fan discharge and faced away from the prevailing
winds.
