Energenics MLF-1015 - Manual

1
www.energenics.com
1470 Don Street

Naples, Florida 34104 Telephone: (239) 643-1711
Fax: (239) 643-6081
Customer Service: (800) 944-1711
2009 Installation & Operation Manual
For MILNOR MLF-1004/1010/1015 On-board or Remote mounted
Individual Lint Filters
Descriptions
Page
Table of Contents
1
Description of Lint Filter Operation
2
Important Installation Considerations
Receiving and Installation
3
Warnings/Cautions
4
Start Up and Operation Instructions
Typical On-Board Installation
5
Typical Remote Installation
6
Utilities Installation 7
Sheet Metal Installation
8
Compressed Air Requirements
9
Fire Suppression Water System
10
Dryer/Filter Utility Requirements
11
Side View Connection Location
12
IMPORTANT WARNING/GATE VALVE MAINTENANCE
13
Optional 6
” Vacuum with 150 Gallon Lint Storage
14
Motor Starter Wiring for Optional Vacuum
15
Maintenance Requirements 16
