2
INSTALLATION OPTIONS
CEILING
SUSPENDED
A
• Allows minimum duct elevation changes, least elbows, and straightest
duct runs.
• Threaded rod suspension.
• Ducting to floor level for lint collection with Energenics flexible connector
to 55 gallon drum.
• Controls mounted on wall or beam at shoulder height.
• 48 inch roof penetration and duct, gooseneck duct on the roof or Optional
Energenics’ supplied side discharge.
• Energenics side discharge available for inside mounting and exhausting
out the side wall.
FLOOR MOUNTED
ON TOWER
B
• Allows minimum duct elevation changes, least elbows, straightest duct
runs.
• Optional Energenics supplied 4 inch tubular tower can be adjusted for
height to match ceiling restrictions.
• All controls should mounted on the tower at shoulder.
• 48 inch roof penetration and exhaust duct.
FLOOR MOUNTED
C
• Requires significant duct elevation changes, thus increasing ducting
backpressure.
• Must be ordered with optional (no cost) legs.
• Can order Pre Plumb option with control mounted on the filter by
Energenics.
• Mounts over 55 gallon drum with Energenics flexible connector.
• Gooseneck duct on the roof or Energenics optional side discharge.
• Energenics side discharge option also available for inside mount and side
wall discharge.
• Gooseneck duct on the roof or Energenics supplied options side
discharge.
