3
RECEIVING AND INSTALLATION
Before you sign the Bill of Lading :
1. Receiving- Inspect units inside and out for signs of damage
Verify all components are delivered per the Bill of Materials.
Report damage to the carrier IMMEDIATELY.
Note ALL damage on the Bill of Lading.
This is your responsibility and you must file all claims
.
The filter is fully assembled and ready for installation. If the
optional vacuum system is not ordered there will be a box with
the Lint Bag and Installation Manual.
2. Installation- Follow instructions attached:
Determine the location with reference to minimum duct work from the tumbler
and ease of access for inspection. In most cases the Lint Filter will be
mounted directly to the dryer.
If using a lint drop extension allow enough room for lint to travel down 4’
before the first bend. Max bend angle is 30 degrees.
If using lint bag or container make sure adequate clearance is allowed.
Conduit or Sealtight between filter junction boxes should be ¾ inch.
When mounting the filter overhead, mount the control below the filter where it
can be easily accessed.
SUPPORT THE LINT FILTER EXTERNALLY FROM THE
DRYER. DO NOT EXPECT THE DRYER TO SUPPORT THE
LINT FILTER. DO NOT SUPPORT THE DUCTWORK WITH THE
LINT FILTER. ALL DUCTING SHOULD BE SUPPORTED
EXTERNALLY, IN NO CASE BY THE DRYER OR LINT FILTER.
USE THREADED ROD TO STABALIZE THE FILTER AT THE 3
CONNECTION POINTS ON TOP OF THE FILTER TO A
SUPPORT POINT AT THE CEILING.
