PIPING TO BE INSTALLED AS SHOWN ON PAGE 14.
IF SYSTEM IS EQUIPPED WITH VACUUM, IT IS
ABSOLUTELY ESSENTIAL TO INSTALL PVC TUBING IN
A MANNER THAT WILL ALLOW THE GATE VALVE
ASSEMBLY TO BE REMOVED FOR PERIODIC
MAINTENANCE AND CLEANING.
FOR CLEANING AND MAINTENANCE THE GATE
ASSEMBLY MUST BE DISASSEMBLED BY REMOVING
THE NUTS FROM THE HOUSING, REMOVING THE
RUBBER SEALS AND BLOW COMPRESSED AIR ISIDE
THE PLASTIC BODY.
REASSEMBLE FOLLOWING THE REVERSE
PROCEDURE APPLIED IN DISASSEMBLY.
FAILURE TO MAINTAIN THE GATE VALVE WILL
RESULT IN THE SLIDE NOT MOVING TO THE OPEN
POSITION WHICH WILL RESULT IN PACKING OF THE
INSIDE OF THE LINT FILTER. PACKING OF THE FILTER
WILL RESULT IN SCREEN FAILURE AND POSSIBLE
DAMAGE TO THE LINT FILTER HOUSING.
