V. If all the procedures have been checked and there is still no signal:
T
ROUBLE
S
HOOTING
T
ECHNICAL
D
ATA
If no signals can be received on the radio, check the unit by following the procedures described
below.
l. If battery operated, check the following:
AC/DC switch set to "DC" POSITION.
Batteries are correctly inserted, and fully charged. 1.
2.
ll. If house current is being used, check the following:
AC/DC switch set to "AC" POSITION. 1. 1.
Send the unit to a qualified service center for repair. 1.
lll. If DC 12-Volt adapter operated, check the following:
Cigar lighter adapter cord is properly connected to a working 12-Volt receptacle and firmly
inserted in the DC 12V Jack located on the back of the radio cabinet.
AC/DC switch set to "DC" position. 1.
2.
lV. If the procedure described above have been checked and are correct, check the following:
Power switch set to "ON" position.
Radio/P.A. switch set to "Radio" position.
VOLUME set to an audible level.
SW & Air transmissions are not constant-set radio at desired band with volume control high
and wait for transmissions. 1.
2.
3.
4.
Frequency Range:
Mains Power Supply:
Battery Power supply:
Power Output:
Power Consumption:
Dimensions:
Weight:
AM:
CB:
SW1:
SW2:
FM:
AIR:
TV1:
TV2:
VHF:
WB:
120V 60 Hz
6V DC, 4 "D" BATTERIES
1W
5W
15.0"(W) X 10.2"(H) X 6.1"(D)
5.6 POUNDS (without batteries)
530-1710kHz
26.965 - 27.405 MHz CHANNELS: 1 - 40
4.0 - 6.0 MHz
7.0 - 12.0 MHz
88 - 108 MHz
108 - 135 MHz
59.75 - 87.75 MHz CHANNELS: 2 - 6
176 - 218 MHz CHANNELS: 7 - 13
145 - 175 MHz
162.4 - 162.55 MHz
Part No. : 21-2043
301-01 Printed in China
