Figure 2
Operating Controls
Please Note:
Controls shown are for the model indicated.
The location of these controls may vary on the
different models.
Due to improvements and changes in the
equipment, the illustration shown may be dif-
ferent from the actual machine.
Depth Control
Handwheel Knob
Engine Stop Switch
Throttle
Control
Choke Control
Guide Bar
Guide Pointer
Gasoline Powered
Electric Powered
Figure 3
Motor Starter
Reset/Stop
Start Switch Box
Depth Control
Handwheel Knob
Guide Bar
Electrical Plug
“WHIPCHEK
TM
”
Safety Cable
( DS-18 SHOWN)
(SB-14 SHOWN)
Recoil
Starter Grip
Figure 4
Belt Tension Adjustment
Pneumatic Saw
Depth Control
Handwheel Knob
Oil Regulator Knob
Oil Sight Glass
Guide Bar Filter Sight
Glass
Air Pressure
Gauge
Air Hose
Coupler
Air Regulator
Valve
(ASB-14 SHOWN)
(Do not adjust air supply
without “WHIPCHEK
TM
” cable
being properly installed.)
Water
Valve Lever
Water Hose
Connector
Optional
Vacuum
Port
Lifting Bail
