General information
Thank you for purchasing
products. The represents more than 30
years of expertise in transducer and enclosure
design, achieving a system that utilises the most
advanced
sound reinforcement technology to
deliver outstanding audio performance and
maximum reliability.
This manual contains the required information
to make the best use of the system you have
purchased. Please take the time to read it.
Our Web site at contains
further support information such as enclosure and
system drawings, data for modelling software,
architectural
specifications and specification
sheets.
DR series
www.dasaudio.com
INTRODUCTION
3
DR-108A
DR-112A
DR-115A
DR-15A / DR-15AW
!
!
!
!
!
!
! 8”woofer.
Medium / low power.
Medium sensitivity.
Medium throw.
Optional mounting accessory.
High frequency compression driver with 1” coil.
Hanging points (M8): 3 lower.
!
!
!
!
!
!
!
12”woofer.
Medium power.
Medium sensitivity.
Medium throw.
Optional mounting accessory.
High frequency compression driver with 1.34”
coil.
Hanging points (M8): 3 upper and 2 lower.
!
!
!
!
!
!
!
15”woofer.
Medium power.
Medium sensitivity.
Medium throw.
Optional mounting accessory.
High frequency compression driver with 1.34”
coil.
Hanging points (M8): 3 upper and 2 lower.
!
!
!
!
!
!
!
!
15” woofer.
High frequency compression driver with
coil.
Medium power.
Medium sensitivity.
Medium throw.
Optional mounting accessory.
Optional “W” version.
1.34”
Hanging points (M8): 2 upper, 2 lower and 4 rear.
General features
Amplifier features
(Models:
and ) DR-15ADR-15AW DR-108A
?
?
?
?
?
?
?
DMAT (Discrete Monolithic Amplifier
Technology) 150W amplifier for the low frequencies
and 50W for the high frequencies.
Active limiter system.
Linkwitz-Riley crossovers for greater vocal
clarity.
Plug & play self-powered systems.
Power, signal presence and overload indicator
lights (LEDs) let you know what is going on.
Built-in 2-channel mixer with line and
microphone inputs allows all-in-one operation for
the most compact applications.
Balanced line output for daisy-chaining as
many units as needed.
Amplifier features
(Models:
and )
DR-112A DR-115A
? State of the Art amplifier technology including
class-D high efficiency low weight amplifiers.
Plug & play self-powered systems.
XLR (Cannon) balanced input.
XLR (Cannon) parallel output.
Line and microphone use.
300W amplifier for lower frequencies and
100W for upper frequencies.
?
?
?
?
?
EN
