5.
UPDATING A CABINET
To upgrade a cabinet follow the next steps:
1.
Connect the USB side of the USB-RS485 converter provided by D.A.S. Audio to
a free USB port on the computer.
2.
Connect the cabinet which will be upgraded to one zone of the DASnet Rack
using the Ethercon cable.
3.
Connect XLR side of the USB-RS485 converter provided by D.A.S. Audio to the
zone of the DASnet Rack where the cabinet is.
4.
Run the DASLoader software.
5.
Select the Com Port associated to the USB-RS485 converter.
6.
Switch on the device.
7.
Wait for the device to be fully operative and press
Connect
.
8.
DASLoader will:
a.
Be connected to the device under DASnet protocol.
b.
Detect automatically the model of the connected device.
c.
Check the version of the firmware of the detected device.
d.
If the firmware’s version is the last one, DASLoader will show the
message: “Device has latest Version” in the panel info and will
disconnect the device automatically.
e.
If the firmware’s version is not the last one, DASLoader will ask if you
want to update the device now.
