4. INTRODUCTION
Congratulations on your purchase of the Cymatic Audio uTrack 24! The uTrack 24 is three powerful
products in one:
• A 24-track solid-state recorder
• A 24-track digital audio file player
• A 24-input, 24-output computer audio interface
Never before has such a powerful combination of features been available at such an affordable
price, and in such a compact footprint. The uTrack 24 records to and plays back from standard,
off-the-shelf USB drives, while offering a large complement of professional features.
With its large detailed display and generous complement of dedicated front-panel hardware
controls, operation is extremely intuitive and straightforward. Recording is never further away
than a single push of the dedicated front panel “Record” button.
The uTrack 24 is also ready for the future; a dedicated expansion slot allows for alternate audio
I/O to be added, while a network port allows for alternate control mechanisms.* The uTrack 24
also offers user-installable firmware upgrades, so that new features and capabilities may be
added in the future.
5. UTRACK 24 FEATURE LIST
24-Channel Multitrack Recorder
• Allows connection of 24 channels of balanced input/output through 25-pin D-Sub connectors
• Alternate format 24x24 audio I/O using future optional digital expansion modules
• Up to 24-bit resolution, 96kHz sample rate
• Records directly to standard USB drives, attached to convenient front-panel USB port
• 3-segment hardware input metering per input channel, also works as 24-segment full scale
meter
• Large, easy to use illuminated front panel transport buttons
• Internal DSP mixer offers stereo monitor mix of all 24 inputs through front-panel headphone
output and rear panel monitor outputs, with dedicated level controls. Adjust level, panning,
mute, and solo for all 24-inputs while enjoying detailed 24-segment hardware input/output
metering, all with no external mixer required!
• Synchronize two uTrack 24 recorders for a total track count of 48 tracks *
• RJ-45 Network connection for future remote control from external software *
• BNC Word Clock Input/Output allows integration into larger digital systems
• Large, detailed LCD screen, dedicated menu buttons, and rotary push control allow for fast
and intuitive adjustment of various settings
24-Channel Multi-Track Player
• Play back 24 tracks of audio, perfect for virtual sound checks or expanding live
performances with individual pre-recorded tracks
• Synchronized Play back of Standard MIDI Files *
• Edit song order on the fly, during playback, directly from the front panel
• Playback start and stop via optional footswitch
• On the fly loop playback and mark-in/mark-out points allows for easy looping
• Free downloadable playlist editor allows you to easily create custom audio playlists, with
customization capabilities such as:
○ Assigning an audio file’s output channel
○ Creating set lists
○ Set pause times between songs
○ Assigning continuous play between songs
24-input, 24-output Computer Audio Interface
• Dedicated control room and headphone outputs with individual hardware level controls
• 24-bit/96kHz support
• Compatible with OSX, Windows, and iOS
6. WHAT’S IN THE BOX
Your uTrack 24 comes with the following materials:
• uTrack 24
• AC/DC Power Adapter and power cable
• Removable Rack Ears
• USB Cable
• Printed Quick Start Guide
7. HOW TO USE THIS USER’S MANUAL
This user’s manual is one of several documents available to you that detail different aspects of
the uTrack 24 and its accessory software:
• This document is the full user’s manual. Refer to it for the most comprehensive information
about the uTrack 24 and all of its operations.
• An 8-page printed “Quick Start Guide” is included in the box. Refer to the quick start guide
for a concise how-to lesson on getting started with the product.
• The uTrack 24 works with free downloadable software named “WavTool”, that allows you to
convert the uTrack 24’s multi-channel broadcast wave files into standard mono wave files.
Download the WaveTool and its user’s manual at www.cymaticaudio.com
• The uTrack 24 also works with the free downloadable playlist editor software which allows
you to create custom playlist that can be played back on the uTrack 24. Download the
Playlist Editor and its user’s manual at www.cymaticaudio.com
* Available in future firmware update
