6
FIG 1 CLEARANCES TO COMBUSTIBLES
FIG 2 BURNER ASSEMBLY DETAIL
12” 12”
1/2” SCREW
CROSS-OVER
AIR SHUTTER
ORIFICE
BURNER VALVE
VENTURI
AIR INLET
5/16” x 5/8”
APPROX
BURNER
24”
