Cavity Blade Fuse Cartridge Fuse Description
F88 10 Amp Red –
Collision Mitigation Module (CMM)/
Electrochromatic Mirror/Haptic Lane
Feedback Module (Half)/Humidity
Sensor– If Equipped
F89 – – Not Used
F90 – – Not Used
F91 – – Not Used
F92 – – Not Used
F93 – 40 Amp Green
Brake System Module (BSM) – Pump
Motor – If Equipped
F94 – 30 Amp Pink Electric Park Brake (EPB) – Right
F95 10 Amp Red –
Electrochromatic Mirror/Rain/Pass.
Window SW/Power Outlet Console
Illumination/Sensor/Sunroof – If Equipped
F96 10 Amp Red –
Occupant Restraint Controller (ORC)
(Airbag)
F97 10 Amp Red –
Occupant Restraint Controller (ORC)
(Airbag)
F98 25 Amp Clear – Audio Amplifier – If Equipped
F99 – – Not Used
F100 – – Not Used
Interior Fuses
The interior fuse panel is located in the passenger compartment on the left side dash panel under
the instrument panel.
Cavity Blade Fuse Description
F13 15 Amp Blue Low Beam Left
F32 10 Amp Red Interior Lighting
F36 10 Amp Red Intrusion Module / Siren
F37 7.5 Amp Brown Aux. Switch Bank Module (ASBM)
F38 20 Amp Yellow All Doors Lock/Unlock
F43 20 Amp Yellow Washer Pump Front
F48 20 Amp Yellow Horns
F49 7.5 Amp Brown Lumbar Support
F51 10 Amp Red
Driver Window Switch / Power Mirrors –
If Equipped
F53 7.5 Amp Brown UCI Port (USB & AUX)
F89 5 Amp Tan Trunk Lamp
F91 5 Amp Tan Fog Lamp Front Left
F92 5 Amp Tan Fog Lamp Front Right
F93 10 Amp Red Low Beam Right
