FUSES
Power Distribution Center (Fuses)
The Power Distribution Center is located in the engine compartment near the battery. This
center contains cartridge fuses, mini-fuses and relays. A label that identifies each component is
printed on the inside of the cover.
Cavity Blade Fuse Cartridge Fuse Description
F06 – – Not Used
F07 – – Not Used
F08 25 Amp Clear –
Engine Control Module (ECM) /
Fuel Inj.
F09 – – Not Used
F10 20 Amp Yellow –
Power Transfer Unit (PTU) –
If Equipped
F11 – – Not Used
F12 20 Amp Yellow – Brake Vacuum Pump – If Equipped
F13 10 Amp Red –
Engine Control Module (ECM) / VSM
(Stop/Start Only)
F14 10 Amp Red –
Drivetrain Control Module (DTCM) /
Power Transfer Unit (PTU) –
If Equipped / RDM / Brake System
Module (BSM) / Brake Pedal S.
F15 – – Not Used
F16 20 Amp Yellow – Powertrain / Ignition Coil
F17 – – Not Used
F18 – – Not Used
F19 – 40 Amp Green Starter Solenoid
F20 10 Amp Red – A/C Compressor Clutch
F21 – – Not Used
F22 5 Amp Tan – Radiator Fan Enable
F23 70 Amp Tan – Body Controller Module (BCM) – Feed 2
F23 50 Amp Red –
Voltage Stability Module (VSM) #2 –
If Equipped With Stop/Start
Engine Option
F24 – – Not Used
F25B 20 Amp Yellow –
Front Washer Pump – If Equipped with
Stop/Start Option
F26 – – Not Used
F27 – – Not Used
F28 15 Amp Blue – Transmission Control Module (TCM)
F29 – – Not Used
F30 10 Amp Red – Engine Control Module (ECM) / EPS
