Rear Power Distribution Center Fuses
Cavity Fuse
Circuits
1
60 Amp Clear
Ignition Off Draw
2
40 Amp Green
Battery
3
—
—
4
40 Amp Green
Battery
5
30 Amp Pink
Heated Seat/Steering Col-
umn
6
20 Amp Yellow
Fuel Pump
7
—
—
8
15 Amp Dk. Blue Ignition Start/Run - Start
9
20 Amp Yellow
Console Power Outlet
10
10 Amp Red
Rear Fog Lamp — If
Equipped
11
25 Amp C/BRKR Memory Module/Door
Locks
12
25 Amp C/BRKR Passenger Power Seat
13
30 Amp C/BRKR Door Module Run/Acc/
Delay
14
10 Amp Red
Sentry Key/Remote Key-
less Entry/Cluster
Cavity Fuse
Circuits
15
—
—
16
—
—
17
—
—
18
20 Amp Yellow
Selectable Power Outlet
19
10 Amp Red
Stop Lamp
20
—
—
21
—
—
22
—
—
23
—
—
24
—
—
25
—
—
26
—
—
27
10 Amp Red
Airbag/Occupant Classifi-
cation Module
28
10 Amp Red
Curtain Airbag - if
equipped
29
5 Amp Orange
Sentry Key/Remote Key-
less Entry/Powertrain
Control Module Ignition
Feed
