Front Power Distribution Center Fuses
Cavity Fuse
Circuits
1
20 Amp Yellow
Left High Beam Headlight
2
20 Amp Yellow
Right High Beam Head-
light
3
—
—
4
20 Amp Yellow
Horn
5
25 Amp Clear
Headlamp Washer
6
15 Amp Dk. Blue Front Control Module
(FCM)
7
20 Amp Yellow
Fog Lamp
8
15 Amp Dk. Blue Park Lamp
9
15 Amp Dk. Blue Non ABS Brakes
10
5 Amp Orange
Starter
11
20 Amp Yellow
Auto Shutdown/
Powertrain Control Mod-
ule (PCM)
12
—
—
13
—
—
Cavity Fuse
Circuits
14
25 Amp Clear
Powertrain Control Mod-
ule
15
20 Amp Yellow
Injectors, Ignition Coils
16
15 Amp Dk. Blue Powertrain Control Mod-
ule
17
30 Amp Pink
Antilock Brake System
(ABS) Valves
18
30 Amp Pink
Windshield Wiper/Washer
19
50 Amp Red
Radiator Fan
20
20 Amp Lt. Blue
Starter
21
50 Amp Red
ABS Pump Motor
22
40 Amp Green
Radiator Fan High/Low
23
50 Amp Red
High Intensity Lighting
24
60 Amp Yellow
Radiator Fan
25
30 Amp Pink
Lighting Left High Beam/
Right Low Beam
26
—
—
27
30 Amp Pink
Lighting Left Low Beam/
Right High Beam
