3 REMOTE CONTROL UNIT
Following the procedure outlined below, insert the batteries before using the remote control unit.
Range of operation of the remote control unit
n Inserting the batteries
1, Open the bottom cover of the remote control unit and
remove the battery cover.
2. Insert the two R6P/AA batteries, matching the © and
0 marks on the batteries with those in the case.
Close the bottom cover until it clicks shut.
Point the remote control unit at the remote control sensor as
shown on the diagram at the left.
NOTES:
• The remote control unit can be used from a straight distance of
approximately 7 meiers/20 feet, but this distance will shorten
or operation will become difficult if there are obstacles
between the remote control unit and the remote control
sensor, if the remote control sensor is exposed to direct
sunlight or other strong light, or if operated from an angle.
• Neon signs or other devices emitting pulse-type noise nearby
may result in malfunction, so keep the set as far away from
such devices as possible.
NOTES
• Use only AA, R6P, UM-3 batteries for replacement.
•
Be sure the polarities are correct. {See the illustration inside
the battery compartment.}
• Remove the batteries if the remote control transmitter will not
be usedjor an extended period of time.
• if batteries leak, dispose of them immediately, Avoid touching
the leaked material or letting it come in contact with clothing,
etc. Clean the battery compartment thoroughly before install­
ing new batteries.
• Have replacement batteries on hand so that the old batteries
can be replaced as quickly as possible when the time comes.
• The codes that have been learned may be lost if removed
batteries are not replaced within about 5 minutes.
3-1 System code buttons
DENON remote-controllable audio components can be controlled using this unit's remote control unit.
Note that some components, however, cannot be operated with this remote control unit.
1. Set to slide switch to "AUDIO" ("AVR/
AVC").
AUDIO -----------
3 q _
AVR/AVC VIDEO"
2. Set the slide switch to the position for the
component to be operated (CD, DECK or
DAT).
-CD DECK OAT
-VOP VCR TV
3. Use the buttons shown below to operate the
component.
For details, refer to the respective compo­
nent's manual.
a. For CD players and DATs
J izzJ
C5)
b. For tape decks
(3 E)
( a T s )
QD
O
OiSC_£^-i
o
QD GD
®—i
DENON
i^V^o --
dD GD QDl O
StSTCW j aj*<.ui'cn
w w ■ ■ J MVii
® © 3)LS.
®”(5) ® d)
MULTI V AuKrQAve _
d) S 0.
siFftEO MPOE r
O O O /0^
o
cMifi
o
y,io«e
o O
o 5
Q O
O ^ O
y
O
©
CD
CD
O
