PARTS LIST OF EXPLODED VIEW
Ref. No. ■ Part No. Part Name Remarks
• 1 411 1000 652 CHASSIS Europe, U.K.
411 1000 681 CHASSIS U.S.A., Canada
411.1000 665 CHASSIS Multi-Voltage
•; 2 412 2523 115 EARTH BRACKET
•) 3 105 0787*107 BOTTOM COVER
4 338 0168 009 CASSETTE MECHANISM
Í. 5 ■'233'^'5«)5' ^ER'TRANSFORMER ’' Europe, U.K, .
.Í, 233 5758 009 POWER TRANSFORMER - U.S.A., Canaria ,
A . 233 5760 000 POWER TRANSFORMER Multi-Voltage
A 6 , 212 0286 003 POWER SWITCH . , • (SW001) ' ' ■
A 1 " 206 2089 106 i AC CORD WITH CONNECTOR J Europe
A
206 2128 009 AC CORD WITH CONNECTORU.K.
A- 206 2110 004 AC CORO WITH CONNECTOR. ’ ■ U.S.A., Canada '
A - 206 2088 000 AC CORD WITH CONNECTOR ' ' Multi-Voltage 7. »•
A 8 445 0056 008 CORD BUSH , , •
• 9 412 2008 012 BUSHING PLATE
• n 414 0637 009 SHIELD LABEL
12 104 020a2-U^ FOOT ASS’Y 1.
. 13 GU-2778 AUDIO/METER P.W.B UNIT
, 13-1 — AUDIO P.W.B.
, 13*2 — METER P.W.B.
* 13-3 — H/P JACK P.W.B.
• 13-4 VARI PITCH P.W.B,
. 14 3U-2603 POWER TRANS P.W.B. UNIT
15 205 0712 074 7P TBG-S CONNECTOR
16 204 8261 003 4P PIN JACK (jK3oi:
18 211 0707 000 VARIABLE RESISTOR 100K V0920V25FA104
19 412 3951 003 REFLECTOR
21 211 0835 008 VARIABLE RESISTOR 5K V1620V35FA502 (MG)
22 204 8264 026 HEAD PHONE JACK
- 23 393 8002 009 EL TUBE (FIP6BGM6) (FL601)
25 431 0310 046 POWER SWITCH LEVER
ASS'Y
26 113 1481 364 PUSH KNOB (B)
27 113 1436 393 FUNCTION KEY
28 113 1480 255 PUSH KNOB (A)
29 113 1438 045 EJECT KNOB
30 112 0515 173 VOLUME KNOB
31 112 0727 042 VOLUME KNOB (C)
• 32 103 1650 101 FRONT ESCUTCHEON ASSY iTK)
* 33 143 0765 215 METER WINDOW
• 34 144 2309 216 FRONT PANEL
35 103 1511 318 CASSETTE BOX
36 463 0655 009 CASSETTE SPRING
37 463 Ò659 018 BOX SPRING [R)
38 103 1660 007 CASSEHE WINDOW lA) ASS'Y
39 421 9007 007 MINI DAMPER
• 40 414 0595 015 EARTH PLATE
• 41 203 2279 014 2C TERMINAL WIRE 3T
• 45 102 0434 419 TOP COVER
• 46 473 8047 001 SPECIAL SCREW
• 47 412 3676 207 EJECT LEVER
• 48 412 3628 006 LEVER STAY (B|
• 49 463 8238 004 SPRING
• 50 412 3677 015 MOUNT BRACKET
• 51 445 8028 009 CORD HOLDER
• 53 513 2150 001 WARNING SHEET
* 54 412 3942 009 VOLUME BRACKET
101 473 7508 017 3 X 10 CBTS(P)-B
102 477 0262 006 SPECIAL SCREW
103 473 7502 013 4 X 10 CBTS(P)-Z
104 473 7509 058 4 X 1 2 CBTS(P)-B
105 473 7500 044 3X8 CBTS(P)-B
106 473 7002 018 3X8 C8TS(S)-Z
107 473 7007 039 4 X 20 CBTS(S)-B
108 471 3102 013 2 X 5 CBS-Z
and/or shading have special characteristics Important
WARNING:
• Parts marked with
to safety.
Be sure to use the specified parts for replacement.
• Part indicated with the mark are not always in stock and possibly to take a
long period of time for supplying, or in some case supplying of part may be
refused.
