Toshiba Power Inverter - Manual (Page 5)

PAGE
No.
DEVICE DESCRIPTION
932kVA. 480V. 1121A lOOOkVA. 480V. 1203A 1200kVA. 480V. 1443A
TYPE FORM RATING PART NUMBER TYPE FORM RATING PART NUMBER TYPE FORM RATING PART NUMBER
8 ® MCCB1 CIRCUIT BREAKER SOD PJL36000S12-RE10 600V. 1200A. 3P. 65KAIC®480V PC11001P014 SOD PJL36000S12-RE10 600V. 1200A. 3P. 65KAIC®480V PC11001P014 SMS RD63F200 600V. 1600A. 3P. 50KAIC®480V PC11356P200
® MCCB1. 2 MOLDED CASE SWITCH SOD PJL36000S60-RE10 600V. 600A. 3P. 65KAIC®480V PC11001 poll SOD PJL36000S60-RE10 600V. 600A. 3P. 65KAIC®480V PC11001 poll SOD PJL36000S80-RE10 600V. 800A. 3P. 65KAIC®480V PC11001P012
MCCB3 CPT1 PRIMARY CIRCUIT BRKR SMS ED62B015 600V. 15A. 2P. 25KAIC®480V PC11321P015 SMS ED62B015 600V. 15A. 2P. 25KAICO480V PC11321P015 SMS ED62B015 600V. 15A. 2P. 25KAIC®480V PC11321P015
8FU3 CPT1 SECONDARY FUSE GLD TRM 20 20A. 250V. TD. 10KAIC PC26130P034 GLD TRM 20 20A. 250V. TD. 10KAIC PC26130P034 GLD TRM 20 20A. 250V. TD. 10KAIC PC26130P034
® FRA.B~FTA.B SEMICONDUCTOR FUSE CRF A060URD32TTI1250 600V. 1250A (X6) PC15360P120 CRF A060URD32TTI1250 600V. 1250A (X6) PC15360P120 CRF A060URD32TTI1250 600V. 1250A (X6) PC15360P120
ffl FRA.B~FTAB SEMICONDUCTOR FUSE CRF A060URD32TTI1250 600V. 1250A (X6) PC15360P120 CRF A060URD32TTI1250 600V. 1250A (X6) PC15360P120 CRF A060URD32TTI1250 600V. 1250A (X6) PC15360P120
BFI BLOWN FUSE INDICATOR CRF MS3V1-5BS 250V. 3A PC15360P001 CRF MS3V1-5BS 250V. 3A PC15360P001 CRF MS3V1-5BS 250V. 3A PC15360P001
CPT1 CNTL. PWR. TRANSFORMER GTI GT-F852 380/400/415/460:230V. 3.3kVA PC33130P331 GTI GT-F852 380/400/415/460:230V. 3.3kVA PC33130P331 GTI GT-F852 380/400/415/460:230V. 3.3kVA PC33130P331
® ACL1~3 OUTPUT LINE REACTOR — — — — — — TCI KLR480BCB 480V. 480A. 1.5% PC34092P400
® ACL1~3 OUTPUT LINE REACTOR TCI KTRSWA400XA 600V. 441 A. 0.120mH. 2.2kHZ PC34097P502 TCI KTRSWA400XA 600V. 441 A. 0.120mH. 2.2kHZ PC34097P502 TCI KTRSWA500XA 600V, 588A. 0.077mH. 2.2kHZ PC34097P501
® CAP1~6 FILTER CAPACITOR SHZ M-N3015-A 200UF. 3PH. 460VAC. 50A PC14150P021 SHZ M-N3015-A 200UF. 3PH. 460VAC. 50A PC14150P021 SHZ M-N0044-D 250UF. 3PH. 460VAC. 75A PC14150P020
® 8FU4~15 FILTER CAPACITOR FUSE CRF 6.9gGR SIB NHOO 125A. 690VAC PC15360P010 CRF 6.9gGR SIB NHOO 125A. 690VAC PC15360P010 CRF 6.9gGR SIB NHOO 125A. 690VAC PC15360P010
® BFI BLOWN FUSE INDICATOR CRF F210156C 250V. 10A PC15360P011 CRF F210156C 250V. 10A PC15360P011 CRF F210156 250V. 10A PC15360P011
HCTB. HCTC HALL CT LEM HAX-1000-S/SP11 1125A:4V PC30013P063 LEM HAX-1200-S 1200A:4V PC30013P050 LEM HAX-1500-S/SP11 1450A:4V PC30013P064
g MSI SOFT START CONTACTOR TMQ LC1F4004U7 400A. 600V. 4P PCI 8701P026 TMQ LC1F4004U7 400A. 600V. 4P PCI 8701P026 TMQ LC1F500U7 500A. 600V. 3P PCI 8701P025
MS2 CAP DISCHARGE CONTACTOR CLK 7001-5150-21 40A. 500VDC. IP PC18720P013 CLK 7001-5150-21 40A. 500VDC. IP PC18720P013 CLK 7001-5150-21 40A. 500VDC. IP PC18720P013
OH1T~OH3T T-STAT 75‘C FIXED N.C. TKN OHD3-75B 75‘C 45811 TKN 0HD3-75B 75‘C 45811 TKN 0HD3-75B 75‘C 45811
OH1B~OH3B T-STAT 90’C FIXED N.C. TKN OHD3-90B 90‘C 37619 TKN OHD3-90B 90‘C 37619 TKN OHD3-90B 90‘C 37619
THR1 HEATSINK THERMISTOR FEN 590-32BP01-203 2KOHM ® 25 DEG C 41935 FEN 590-32BP01-203 2K0HM ® 25 DEG C 41935 FEN 590-32BP01-203 2K0HM ® 25 DEG C 41935
R1 SOFT START RESISTOR PWO WR33 0.67 OHM. 300W. 2S PC41490P052 PWO WR33 0.67 OHM. 300W. 2S PC41490P052 PWO WR33 0.67 OHM. 300W. 2S PC41490P052
R2 CAP DISCHARGE RESISTOR PWO SXR2-500 500 OHM. 300W. 3S PC41490P052 PWO SXR2-500 500 OHM. 300W. 3S PC41490P052 PWO SXR2-500 500 OHM. 300W. 3S PC41490P052
REC1A. M. B~6 DIODE PACK EUP DD260N16K 1600V. 260A (XI8) PC40316P260 EUP DD260N16K 1600V. 260A (XI8) PC40316P260 EUP DD260N16K 1600V, 260A (XI8) PC40316P260
® SA1~SA3 SURGE SUPPRESSOR SMS B40K550 500V. 3000J PC47000P003 SMS B40K550 500V. 3000J PC47000P003 SMS B40K550 500V. 3000J PC47000P003
® SA4~SA6 SURGE SUPPRESSOR SMS B40K550 500V. 3000J PC47000P003 SMS B40K550 500V. 3000J PC47000P003 SMS B40K550 500V. 3000J PC47000P003
IGBT7 DYNAMIC BRAKE IGBT EUP FZ600R12KE3 1200V. 600A (X2) PC40200P600 EUP FZ600R12KE3 1200V. 600A (X2) PC40200P600 EUP FZ600R12KE3 1200V. 600A (X2) PC40200P600
D7A. В DYNAMIC BRAKE DIODE SMK SKN60F15 75A. 1500V PC40300P075 SMK SKN60F15 75A. 1500V PC40300P075 SMK SKN60F15 75A. 1500V PC40300P075
C7 SNUBBER CAPACITOR EC 5MP-13086K 5.0UF. 1000VDC 46326 EC 5MP-13086K 5.0UF. 1000VDC 46326 EC 5MP-13086K 5.0UF. 1000VDC 46326
C7A. В SNUBBER CAPACITOR SGU 564R30GAD47 4700pF. 3000V PC42200P003 SGU 564R30GAD47 4700pF. 3000V PC42200P003 SGU 564R30GAD47 4700pF. 3000V PC42200P003
R7 SNUBBER RESISTOR UPE RBN50/8-25R 25 OHM. 50W PC41490P035 UPE RBN50/8-25R 25 OHM. 50W PC41490P035 UPE RBN50/8-25R 25 OHM. 50W PC41490P035
PCB6 DYNAMIC BRAKE G-E PROT 44348A — 44348A 44348A — 44348A 44348A — 44348A
10. 12 HCTA HALL CT NNE HEC-05A(AMO) 500A:4V PC30013P067 NNE HEC-07A(AMO) 677A:4V PC30013P066 NNE HEC-07A(AM0) 677A:4V PC30013P066
CA CAPACITOR HIT HCGF5AS2G123YQ 12kUF. 400VDC (3P/2S) 37568 HIT HCGF5AS2G123YQ 12kUF. 400VDC (4P/2S) 37568 HIT HCGF5AS2G123YQ 12kUF, 400VDC (4P/2S) 37568
FA SEMICONDUCTOR FUSE CRF 6.9URB000BS88 690V. 250A (X3) 52751 CRF 6.9URB000BS88 690V. 250A (X4) 52751 CRF 6.9URB000BS88 690V. 250A (X4) 52751
RA CAP BALANCING RESISTOR DLR RS-10 50 kOHM. low (X6) PC41470P052 DLR RS-10 50 kOHM. low (X8) PC41470P052 DLR RS-10 50 kOHM, low (X8) PC41470P052
FUP. FUN SEMICONDUCTOR FUSE CRF 6.9URD32TTF0800 690V. 800A (X6) 37578 CRF 6.9URD32TTF1000 690V. 1000A (X6) 47244 CRF 6.9URD32TTF1000 690V. 1000A (X6) 47244
BFI BLOWN FUSE INDICATOR CRF MS3V1-5BS 250V. 3A PC15360P001 CRF MS3V1-5BS 250V. 3A PC15360P001 CRF MS3V1-5BS 250V. 3A PC15360P001
IGBT IGBT EUP FZ600R12KE3 1200V. 600A (XI2) PC40200P600 EUP FZ600R12KE3 1200V. 600A (XI8) PC40200P600 EUP FZ600R12KE3 1200V. 600A (XI8) PC40200P600
PCB20~20B SNUBBER CIRCUIT PCB PC61910P117A — PC61910P117A PC61910P117A — PC61910P117A PC61910P117A — PC61910P117A
RP. RN RESISTOR ITK IRH100N 25 OHM. 100W PC41490P038 ITK IRH100N 25 OHM. 100W PC41490P038 ITK IRH100N 25 OHM. 100W PC41490P038
RSI. 1A RESISTOR EBG HPP/4-10R 10 OHM. 60W 53706 EBG HPP/4-10R 10 OHM. 60W 53706 EBG HPP/4-10R 10 OHM. 60W 53706
18 G3 KPD G3 OPERATOR KEYPAD — — 48723 — — 48723 — — 48723
20 DS1 DOOR SWITCH IDE TABD311N-R 10A. 600V PC21230P162 IDE TABD311N-R 10A. 600V PC21230P162 IDE TABD311N-R 10A. 600V PC21230P162
MST TIMER. ON DELAY IDE GT5Y-2SN1A200 240VAC COIL. 0.1S-10M DELAY PC20111P180 IDE GT5Y-2SN1A200 240VAC COIL. 0.1S-10M DELAY PC20111P180 IDE GT5Y-2SN1A200 240VAC COIL. 0.1S-10M DELAY PC20111P180
MSX CONTROL RELAY IDE RR2P-U-AC240V 240VAC COIL. 7A PC20229P326 IDE RR2P-U-AC240V 240VAC COIL. 7A PC20229P326 IDE RR2P-U-AC240V 240VAC COIL. 7A PC20229P326
21 FAN1~3 HEAT SINK FAN ZA RH31M-4/130823 230VAC. 1200CFM. 50/60HZ PC50050P310 ZA RH31M-4/130823 230VAC. 1200CFM. 50/60HZ PC50050P310 ZA RH31M-4/130823 230VAC. 1200CFM. 50/60HZ PC50050P310
C1~3 FAN RUN CAPACITOR CDE SFA37S4K219B-F 370V. 4uF PC42000P412 CDE SFA37S4K219B-F 370V. 4uF PC42000P412 CDE SFA37S4K219B-F 370V. 4uF PC42000P412
FAN11~13 (@FAN7) INTERNAL FAN ETR 148VK0281030 240VAC. 33W. 50/60HZ. 255CFM 00226 ETR 148VK0281030 240VAC. 33W. 50/60HZ. 255CFM 00226 ETR 148VK0281030 240VAC. 33W. 50/60HZ. 255CFM 00226
NK1~3 (®NK7) SURGE SUPPRESSOR MCN RFM25M224KD 250VAC. 0.22uF. 220 OHM 00427 MCN RFM25M224KD 250VAC. 0.22uF. 220 OHM 00427 MCN RFM25M224KD 250VAC. 0.22uF. 220 OHM 00427
S FAN21~26 ENCLOSURE FAN ETR 148VK0281030 240VAC. 33W. 50/60HZ. 255CFM 00226 ETR 148VK0281030 240VAC. 33W. 50/60HZ. 255CFM 00226 ETR 148VK0281030 240VAC. 33W. 50/60HZ. 255CFM 00226
® NK4. 5 SURGE SUPPRESSOR MCN RFM25M224KD 250VAC. 0.22uF. 220 OHM 00427 MCN RFM25M224KD 250VAC. 0.22uF. 220 OHM 00427 MCN RFM25M224KD 250VAC. 0.22uF. 220 OHM 00427
@ HEX1. 2 HEAT EXCHANGER DAN PS060100B-P2 230VAC. 1.0A. 100W/F PC67808P153 DAN PS060100B-P2 230VAC. 1.0A. lOOW/F PC67808P153 DAN PS060100B-P2 230VAC. 1.0A. 100W/F PC67808P153
TCC CONTACTOR TMQ LC1D09U7 240V COIL. 9A. 600V PCI 8701P060 TMQ LC1D09U7 240V COIL. 9A. 600V PCI 8701P060 TMQ LC1D09U7 240V COIL. 9A. 600V PCI 8701P060
29 PCB1 CONTROL BOARD VF5C-1271D — 03828 VF5C-1271D — 03828 VF5C-1271D — 03828
PCB2~2B GATE DRIVE BOARD 42755P4E — 42755P4E 42755P4F — 42755P4F 42755P4F — 42755P4F
PCB3 INTERFACE BOARD PC61910P109A — PC61910P109A PC61910P109A — PC61910P109A PC61910P109A — PC61910P109A
PCB4~4E G-E PROTECT CIRCUIT BOARD 38383C — 38383C 38383C — 38383C 38383C — 38383C
PCB5 TERMINAL BOARD 41578A — 41578A 41578A — 41578A 41578A — 41578A
PCB7 OPTION ROM 58270 VER 7008 58270 58270 VER 7008 58270 58270 VER 7008 58270
NOTES:
0) NEMA 1
OPTION
(D
NEMA 3R
OPTION
® 6 PULSE
^ OPTION
® 12 PULSE
OPTION
(D SINEWAVE
FILTER
OPTION
© NON-
SINEWAVE
FILTER
® IGBT7 OPTION
4
3 04/30/08 ECO 75305-CPT1 WAS SOD JT
2 12/06/07 REMOVED ”NEMA 1 ONLY" FROM NOTE 7. JMP JT JBA
1 10/08/07 ECO 74352 JT JT JBA
0 05/03/06 FIRST ISSUE HHP JT JBA
REV DATE DESCRIPTION BY CHK APPR
TOSHIBA
TOSHIBA INTERNATIONAL CORPORATION
MADE IN HOUSTON. TEXAS U.SA
THIS MATERIAL IS THE EXCLUSIVE PROPERTY OF
TOSHIBA INTERNATIONAL CORPORATION AND SHALL
NOT BE REPRODUCED. USED. OR DISCLOSED TO OTHERS
UNLESS PRIOR WRITTEN AUTHORIZATION IS OBTAINED.
TITLE:
EQUIPMENT RATINGS
3 POWER MODULES 03+B 480VAG
CUSTOMER: PROJECT NUMBER:
REVISION: SCALE:
DRAWING NUMBER:
I808HR05
