VIZIO VX20L HDTV User Manual
Installatlcr < f reparation
Please read this user manual carefully before installing your VIZIO HDTV.
The power consumption of the TV is about 85W, please use the power cord designated for TV. When an
extension cord is required, use one with the correct power rating. The cord must be grounded and the
grounding feature must not be defeated.
The TV should be installed on a flat surface to avoid tipping. For proper ventilation, you must allow space
between the back of the TV and the wall. If you would like to mount your TV on the wall, please see
below ‘Preparing Your LCD HDTV for Wall Mounting’ for additional information. Avoid installing the TV in
places with high humidity, dust or smoke so as not to shorten the service life of the electronic components.
Install the TV in landscape orientation; any 90° clockwise or counter-clockwise installation may induce
poor ventilation and excessive component damage.
VIZIO offers professional installation services. Please contact VIZIO for more information on these
.
PrepaririQ VoLv ) ^
^ i r i t ‘ , ‘ * i r
Wall Mountinq
The VIZIO VX20L can either be kept on the stand base or mounted on the wall for viewing. If you choose
to mount the VX20L on the wall, please follow the instructions below for removing the stand base.
To i"emnv,'e
î and
base
1.
Unplug all of the cables and cords
from your VX20L.
2. Place the VX20L face down on a soft
and flat surface (blanket, foam, cloth,
etc) to prevent any damage to the TV.
3. Push up the plastic panel on the back
of the stand and lift it away once to
releases.
4. Remove the four (4) screws that were
hidden by the panel, while holding the
base.
5. Carefully remove the stand base.
6. The metal bracket remaining will not
interfere with the wall mount.
To find the perfect mount for the VIZIO VX20L, browse VIZIO’s certified
-4623).
mount selection at
Version 5/4/2007
