Page 73: 8) indicator lamps
vmo2008-008-010_b
1. Daytime running lights switch
2. OFF position
3. ON position
Choke Lever
This device features a variable lever to
ease engine cold start.
Position OFF is for normal use with a
warm engine.
vmo2008-008-011_c
OFF POSITION
The full choke position is used for low-
er engine temperature.
vmo2008-008-011_d
FULL CHOKE POSITION
The other positions between OFF and
FULL position, will be use depending
on the engine temperature.
8) Indicator Lamps
vmo2008-008-019_a
TYPICAL
1. Neutral (N)
2. Reverse (R)
3. Ignition switch
Neutral Lamp (GREEN)
When
lit,
it
indicates
the
transmission
is
in
neutral
position.
Reverse Lamp (RED)
When
lit,
it
indicates
the
transmission
is
in
reverse
position.
_____________________
71
