Page 20
Resolution
Maximum Refresh Rate (Hz)
Analog Connection
Digital Connection
640x480
85
60
800x600
85
60
1024x768
85
60
1280x720
85
60
1280x1024
85
60
1440x900
75
60
1600x1200
85
60
1680x1050
75
60
1920x1080
85
60-R*
1920x1200
85
60-R
1920x1440
85
N/A
2048x1536
75
N/A
2560x1600
N/A
60**
* Max HDMI resolution is 1080p
** Only supported when using a dual-link DVI connection
NOTE: 60-R denotes reduced blanking timings are used on single-link DVI connections and may be used with other digital
connections.
Languages supported
24 languages: English, Arabic, Chinese Simplified, Chinese Traditional,
Czechoslovakian, Danish, Dutch, Finnish, French, German, Greek,
Hebrew, Hungarian, Italian, Japanese, Korean, Norwegian, Polish,
Portuguese, Russian, Spanish, Swedish, Thai, Turkish
Maximum power
30.5
Compliance standards
EMC Emissions:
a. CISPR22: 1997/EN 55022:1998 – Class B – Limits and methods of
measurement of radio disturbance characteristics of Information
Technology Equipment
EMC Immunity:
CISPR 24:1997/EN 55024:1998 – Information Technology Equipment –
Immunity Characteristics – Limits and Methods of Measurement.
ATI Radeon HD 4350
HDMI PCIe x16
Graphics Card
Input/Output
connectors
DVI
VGA and HDMI
Board display options
Supports two displays through any combination of two of the three output
ports.
Board configuration
Specification
Description
Graphics Chip
RV710D2
Core clock
600 MHz
Memory clock
800 MHz
Frame buffer
256 MB DDR2, 64 bit wide
Bus type
PCI Express (x16 lanes)
Maximum vertical refresh
rate
85 Hz
Display support
Integrated 400 MHz RAMDAC
Display max resolution
1920 x 1080 digital, 2048 x 1536 analog
ATI Radeon HD 4350 DH PCIe x16 Graphics Card display resolutions and refresh rates
NOTE: Other resolutions may be available but are not recommended as the may not have been tested and qualified by HP
QuickSpecs
Compaq 505B Microtower PC
Technical Specifications - Graphics
DA - 13427 Worldwide QuickSpecs — Version 2 — 10.30.2009
Page 20
