Installation instructions, Sheet 4 of 5, Pole mounted icon – Cooper Lighting Pole Mount Icon User Manual
Page 4: Fig. 5b fig. 6
These instructions do not claim to cover all details or variations in the equipment, procedure, or process described, nor to provide directions for meeting every possible
contingency during installation, operation or maintenance. When additional information is desired to satisfy a problem not covered sufficiently for user’s purpose, please
contact your nearest representative.
6. Making Connections-
Make the fixture connections in the ARM. Insert the wires into the arm and reinstall the WIREWAY DOOR as shown in Figure 6.
Customer First Center • 1121 Hwy 74 South • Peachtree City, GA 30269
IMI-593 AVU040206
Pole Mounted Icon
Sheet 4 of 5
3/11/04
IMI-593
INSTALLATION INSTRUCTIONS
IMPORTANT: READ CAREFULLY BEFORE INSTALLING FIXTURE.
RETAIN FOR FUTURE REFERENCE.
TM
WARNING:
Risk of Electric Shock. Disconnect power at fuse or circuit breaker before installing
or servicing.
Wireway Plug
Nut
Lock Washer
Plain Washer
Fig. 5b
Fig. 6
Wireway
Door
Linear
Arm
Upsweep
Arm
Wireway
Door
