Installation Instructions (cont’d)
Facts to Consider About the
Location
You should carefully choose an indoor location for the new
water heater, because the placement is a very important consid'
eration for the safety of me occupants in tnc building and for
the most economical use of the appliance.
This water heater is
not for use in mobile homes or outdoor installation.
Whether replacing an old water heater or putting the water
heater in a new location, the following critical points must be
observed.
• The location selected should be indoors as close as practical to
the gas vent or chimney to which the water heater vent is
going to be connected, and as centralized with the water pip­
ing system as possible. The water heater, as all water heaters,
wiU eventually leak. Do not install without adequate drainage
provisions where water flow will cause danu^.
ACAUTION
WATER HEATERS EVENTUAU.Y LEAK: Installation of the
water heater must be accomplished in such a manner that if
the tank or aiqr connections should leak, the flow of water will
not cause darrage to the structure. When such locations can­
not be avoided, a suitable drain pan should be installed under
the water heater. Drain pans are awailable at your local Sears
store. Such a drain pan must be not greater than V/t inches
deep, have a minimum length and width of at least 2 inches
greater than the water heater dimensions and must be piped
to an adequate drain. The pan must not restrict combustion air
flow. Under no circumstances is the manufecturer or Sears to
be held liable for any water damage in connection with this
water heater.
AWARNING
INSTMIATIONS IN A№AS WHE№ FLAMMABLE UQUIDS
(VAPORS) ARE LIKELY TO BE PRESENT OR STORED
(GARAGES,
STORAGE, AND UTILITY AREAS, ETC):
FlammaUe liquids (such as gasoHne, solvents, propane (LP) or
butane, etc.), all of which emit flammable vapors, may be
improperly stored or used in such areas. The gas water heater
pilot light or main burner can ignite such vapors. The resulting
flashback and lire can cause deitth or serious bums to anyone h
the area, as welt as property damage.
If installation in su^ areas is your only option, then the installa­
tion must be accomplished in a way that tiw pilot flame and
main burner flame are elevated from the floor at lea^ 18 inches.
While this may reduce the chances of flammable vapors from a
floor spill being ignited, gasoline and other flunmable substances
should never be stored or used in the same room or area con­
taining a gas water heater or other opoi flame or spark produc­
ing appliance.
NOTE: Flammable vapors may be drawn by air currents from
other areas of the structure to the appliance.
AWARNING
Propellants of aerosol sprays and volatile compounds, (clean­
ers, chlorine based chemicals, refrigerants, etc.) bt addition to
being highly flammable in many cases, will also change to cor­
rosive hydrochloric acid when exposed to the combustion
products of the water heater. The results can be hazardous,
and also cause product foilure.
The location selection must provide adequate clearances for ser­
vicing and proper operation of the water neater.
AWARNING
This water heater must not be installed directly on carpeting.
Carpeting must be protected by a metal or wood panel
beneath tee appliance extending beyond tee foil width and
depth of tee appliance by at least 3 inches (76.2mm) in any
direction, or if tee appliance is installed in an alcove or doset,
the entire floor must be covered by the panel. Failure to heed
this warning may result in afire hazard.
AWARNING
Minimum clearances between the water heater and com­
bustible construction are I" at the sides and rear, f" at the
front, and 6" from the vent pipe. Clearance from tee top of the
jacket is 18" on most models. Note that a lesser dimension may
be allowed on some models. Refer to the label on the water
heater adjacent to the gas control valve fr>r all clearances.
VENTllATION
ope ÌÌS vgs
Figure I
I'MIN.
AJR DUCT
AWARNING
A gas water heater cannot operate properly without the cor­
rect amount of ah- for combustion. Do not install in a confined
area such a doset, unless you provide air as shown in tee “Facts
to Consider About the Location" section. Never obstruct the
flow of ventilation air. If you have any doubts or questions at all,
call your gas company. Fêlure to provide the pro^ amount of
combustion air can result in a fire or explosion and can cause
DEATH, SERIOUS BODILY INJUf«; OR PROPERTY DAMAGE.
AWARNING
If this water heater will be used in beauty shops, barber shops,
cleaning establishments, or self-service laundries with dry
cleaning equipment, it is imperative that the water heater or
water heaters be installed so that combustion and ventilation
air be taken from outside these areas. Refer to the "Facts to
Consider About the Location" section of this manual and also
the latest edition of the National Fuel Gas Code, ANSI Z223.I,
also referred to as NF№ 54 for specifics provided concerning
air required.
