SECTION 6
REPAIR PARTS
KENMORE WATER SOFTENER,
MODEL NO. 625.348600
PARTS LIST
KEY
NO.
PART
NUMBER DESCRIPTION
50 7131755 Screw, #6-20 X 7/8 (2 req.)
51 7133008 Meter (incl. 2 ea. of Key No. 50)
52 7171200 Motor Plate
53 0900857 Screw, #6-20
X
3/8 (3 req.)
54 7171250 Bearing
55 7171218 Cam and Gear
56 7169180 Clip (Drain)
57 7172793 Drain Hose Adaptor •
58 7170288 0-ring, 15/16
X
1-3/16 •
59 7178163 Flow Plug, 1.8 gpm
60 7173008 0-ring, 5/8
X
13/16
61 7173024 0-ring, 1-1/8 X 1-1/2
62 7174313 Bearing, Wave Washer
63 7185500 Rotor & Disc
64 7173032 0-ring, 4-1/2 X 4-7/8
65 7185495 Rotor Seal
66 7172989 Seal
67 7171187 Plug (Drain Seal)
68 7129889 Spring
69 7089306 Clip (2 req.) •
70 7077642 Copper Tube, 1” (2 req.) •
71 7170262 0-ring, 1-1/8
X
1-3/8 (4 req.) •
72 7094898 Turbine Support
73 7101548 Turbine
74 7235389 Wire Harness (Sensor)
75 9000803 0-ring
76 7081201 Retainer (Nozzle & Venturi)
77 7195482 Seal (Nozzle & Venturi)
78 7171145 Valve Body
79 7170319 0-ring, 1/4 X 3/8 (2 req.)
KEY
NO.
PART
NUMBER DESCRIPTION
80 7081104 Nozzle & Venturi Housing
81 1202600 Nut — Ferrule
82 7095030 Cone Screen
83 1148800 Flow Plug, .3 gpm
84 7187772 Nozzle and Venturi — Gasket Kit
85 0521829 Flow Plug, .1 gpm
86 7146043 Screen
87 7167659 Screen Support
88 7170262 0-ring, 1-1/8
X
1-3/8
89 7081188 Cap
90 7175199 Wave Washer
91 7171161 Valve Cover
92 7172997 Screw, #10 X 2-5/8 (8 req.)
93 7145186 Switch
94 7140738 Screw, #4-24 x 3/4 (2 req.)
95 7179143 Bypass Valve • (Includes follow­
ing parts)
- 7172882 Stem
- 7173016 0-ring, 1.109 I.D. X 1.387 O.D. (4)
- 7175238 C-ring
♦ 7187065 Nozzle & Venturi Assy. (incl. Key
Nos. 80, and 82 through 89)
♦ 7195995 Parts Pack (includes parts marked
with a •, pages 28, 29 & 31) - order
manuals separately if needed, page
28
♦ 7185487 Seal Kit (incl. Key Nos. 60, 61, 64,
65, 66 and 77).
♦ 42-3433 Drain Tubing, 3/8" I.D. x 20' ©
♦ 42-3431 Drain Hose, 5/8" I.D. x 15'
©
not illustrated
Included in parts pack
7’ length included with softener
