SECTION 6
REPAIR PARTS FOR WATER SOFTENER
Kenmore MODEL NOS. 625.388800 & 625.388880
WATER SOFTENER COMPLETE
KEY
NO.
PART
NUMBER
DESCRIPTION
1
—
Cover Lock {req’d for ship, only)
1
—
Rim Insert (req’d for shipping only)
2
7229948
Cover (main)
3
7233159
Salt Hole Cover (order following
decals)
-
7264582
Instruction Decal
7234545
Salt Hole Cover Decal,
UltraSoft 800
—
7264825
Salt Hole Cover Decal,
UltraSoft 880
4
7252373
Transformer, 24V-1 OVA •
5
7234765
Timer Repl. (PWA)
6
7088033
Clamp Retainer (2 req.)
7
7176292
Clamp Section (2 req.)
8
7232446
Vapor Barrier
9
7229956
Faceplate (order following decal)
-
7268104
Faceplate Decal, UltraSoft 800
-
7264469
Faceplate Decal, UltraSoft 880
10
7232276
Rim (incl. Key No. 11 & 12)
11
7137939
Light Asm
12
7252268
0-Ring
13
7219888
Brinewell Cover
14
7082150
Wing Nut, 1/4"
15
7003847
0-Ring
16
7109871
Brinewell
17
7214236
Decal, Salt Level (i)
18
7234773
Salt Storage Tank
KEY
NO.
PART
NUMBER
DESCRIPTION
19
9003500
Grommet •
20
1103200
Tube Adaptor •
21
0900431
Tube Clamp •
22
7232250
Plastic Screw, 1/4" x 5/8"
23
7116488
Brine Valve Assem. (also see page
6-2)
24
7105047
Replacement Distributor
25
0502272
Resin
26
7235478
Resin Tank (includes Key No. 25)
7170270
0-Ring, 2-3/4" x 3"
28
7077870
Top Distributor
29
7170254
0-Ring, 13/16"
X
1-1/16"
30
7170296
0-Ring, 2-7/8"
X
3-1/4"
31
7265025
Ultra Cleansing Screen,
UltraSoft 880 only
♦
3442699
Resin Bed Cleaner
♦
7195995
Parts Bag, (includes parts marked
with a ♦, pages 6-2, 6-4 & 6-6)
- order manuals separately if
necessary
♦
7258997
Installation Manual
♦
7276563
Owners Manual
♦ not illustrated
:i aligns with top of brinewell
• included in parts bag
6
-
2
