Parts
Kenmore Model No. 625.383060
A. WA1rER SOFTENER COMPLETE
Key No. Part Number Part Description
1 — Cover Lock (Required for shipping only)
1 — Rim Insert (Required for shipping only)
2 7284095 Cover (main)
3 7284134 Salt Hole Cover (order following decal)
— 7284142 Instruction Decal
4 7275907 Transformer, 24V-10VA •
5 7288544 Timer Repl. (PWA)
6 7284582 Faceplate (order following decal)
—
7284566 Faceplate Decal
7 7284621 Rim
8 7219888 Brinewell Cover
9 7082150 Wing Nut, 1/4"
10 7003847 0-Ring
11 7100819 Brinewell
12 7137913 Decal, Salt Level ©
13 7287140 Salt Storage Drum
14 7284613 Plastic Screw, 1/4" x 5/8"
15 0900431 Tube Clamp •
16 1103200 Tube Adaptor •
17 9003500 Grommet •
18 7310202 Brine Valve Assembly (also see pages 44 & 45)
19 7105047 Replacement Distributor
20 0502272 Resin
21 7301017 Resin Tank (including Key No. 20)
22 7170270 0-Ring, 2-3/4" x 3"
23 7077870 Top Distributor
24 7170254 0-Ring, 13/16"
X
1-1/16"
25 7170296 0-Ring, 2-7/8"
X
3-1/4"
26 7141001 Vapor Barrier
27 7176292 Clamp Section (2 required)
28 7088033 Clamp Retainer (2 required)
♦ 3442699 Resin Bed Cleaner
♦ 7287205 Parts Bag (includes parts marked with a • pages 43,
45 & 47). Order manuals separately if needed.
♦ 7282580 Owner’s Manual
♦ Not illustrated.
© Aligns with top of brinewell.
• Included in parts bag.
Questions? Call The Kenmore Water Line 1-800-426-9345
43
