Moving the meat dra^ver and eover...
PULL OUT TO STOP. LIFT THE
To remove the meat drawer:
1. Slide the meat drawer out to stop,
2. Lift the front.
3. Slide the drawer the rest of the way out.
4. Replace in reverse order.
To remove the cover:
1. Tiltfrontof cover up, lift at back, and pull straight
out.
2. Replace in reverse order.
Changing the light hulbs...
WARNING: Betore removing a light bulb, either unplug the refrigerator or disconnect the
electricity leading to the refrigerator at the main power supply. Shock and injury can
occur if electricity remains connected.
1. Reach behind the control console to find bulbs.
2. Remove bulb.
3. Replace with a 40-watt appliance bulb.
Removing the base grille...
To remove the grille:
METAL CLIPS
1. Open the doors.
2. Pull grille outwards as shown.
3. Do not remove Tech sheet fastened behind
grille.
Ice cube trays...
If cubes are not used, they may shrink. The mov
ing cold air starts a slow evaporation. The longer
cubes are stored, the smaller they get.
METAL CLIPS
SUPPORT TABS
To replace the grille:
1. Line up grille support tabs with metal clips.
2. Push firmly to snap into place.
3. Close the doors.
To remove ice:
1. Hold tray at both ends,
2. Slightly twist.
Optional automatic ice maker...
If you have the automatic ice maker accessory,
or if you plan to add one later (Part No. ECKMF-83),
there are a tew things you will want to know:
• The ON/OFF lever is a wire signal arm.
Down...for making ice automatically.
Up...to shut off the ice maker.
DO NOT TURN ICE MAKER ON UNTIL IT IS CON
NECTED TO THE WATER SUPPLY.
• The dial or lever on the side of the ice maker
changes the size of the cubes.
• Shake the bin occasionally to keep cubes sepa
rated, and to obtain increased storage capacity.
• It is normal for ice crescents to be attached by a
corner. They will break apart easily.
LOWER
SIGNAL
ARM TO
START IT
RAISE
SIGNAL
ARM TO
STOP ICE
• You will hear water running when ice maker is
working. You’ll hear ice fall into the bin. Don't let
these sounds bother you.
• The ice maker will not operate until the freezer
is cold enough to make ice. This can take
overnight.
continued on next page
