Whirlpool FGP325A - Manual (Page 17)

C A R I N G F O R Y O U R R A N G E
Lift-up cooktop
1. Remove surface burner grates.
2. Lift front of cooktop at both front corners until
the support rods lock into place.
^WARNING
Personal Injury and
Product Damage Hazard
• Be sure both support rods are fully ex­
tended and in the locked position. Failure
to do so could result in personal injury from
the cooktop accidentally falling.
• Do not drop the cooktop. Damage can
result to the porcelain and the cooktop
frame.
3. Wipe with warm, soapy water. Use a soapy
steel-wool pad on heavily soiled areas.
NOTE: When cleaning under the cooktop on
standing pilot models, be careful not to
extinguish pilots.
4. To lower the cooktop, lift cooktop from both
sides while pressing the support rods back to
unlock them. Lower the cooktop into place.
Replace surface burner grates.
Surface burners
2 .
1. Lift up the cooktop, following the instructions
above.
Before cleaning, remove screws that hold
each of the burners in place. The screws
prevent the burners from moving during
shipment.
Remove the shipping screw with a
Phillips screwdriver, lift the burner up, tilt it to
one side at the end closest to the ignitor and
move it toward the back of the range. This
separates the burner from the gas valve at the
front of the range, so it can be easily removed.
Wipe off surface burners with warm, soapy
water and a sponge after each use. To
remove cooked-on food, soak the burners in
a vinegar and water solution for 20-30
minutes.
Scrub with a plastic scrubbing pad.
If ports are clogged, clean with a straight
pin. DO NOT enlarge or distort the ports.
DO NOT use a toothpick to clean the ports.
3.
4.
17
