Setting the temperature control...
To start, turn control to the middle of the dial. This
setting is designed to maintain the temperature at
or near 0'"F ( --17,8'C) under normal operating
conditions.
Using your freezer
' ìTt
il
Adjusting the temperature control...
1, Turn oontrol to higher number for colder temper­
atures,
2. Turn to lower number for less cold temperatures
Cooling freezer first...
1. Allow freezer to cool 6 to 8 hours before filling with
frozen food.
2. Let it cool overnight before adding large amount
of unfrozen food.
Note: When freezer is first started, the compressor
will run constantly until the cabinet is cooled. It may
take up to 6 to 8 hours or longer, depending on room
temperature and the number of times the freezer
door IS opened
After the cabinet is cooled, the compressor wil
turn ON and OFF as needed to keep the freezer at
the proper temperature
The Power Saving Control...
operates electric heaters. These heaters help pre­
vent moisture from forming on the outside of the
freezer when humidity is high.
1, Use the OFF setting when humidity is low,
2 Use the ON setting only if moisture forms on the
outside of the freezer
Changing the light bulb...
Light Shield
Unplug the freezer first.
1, Remove the light shield from the side of the control
panel, Depress the back of the shield to release the
tabs, then pull away,
2, Replace bulb with a 40-watt appliance bulb
3 Replace the light shield. Insert the shield tabs in the
slots, then press the shield to snap into place
Adjusting the basket shelf...
To remove basket shelf:
1. Remove food from basket,
2. Slide basket straight out to stop.
3. Lift front,
4. Slide the rest of the way out.
To replace basket shelt:
1, Fit book of basket shelf on top of guide stops on
bottom of guides,
2. Lift front, then slide the basket until it clears the
guide stops.
Shelf Guide
