TOP AND CABINET PARTS
IMus.
No.
For Model:
Part
No.
CAM2752TQ0
(White)
DESCRIPTION
1
Literature Parts
8316532 Instructions,
Coin Kit
W10112082 Wiring Diagram
W10114741 Energy Guide
W10114744 Repair Parts List
2
8524688 Top
3
3353950 Spacer, Cabinet To
Top (4)
4
3351614 Screw, Ground
5
3358500 Panel, Front
6
62780 Clip, Top & Cabinet
& Rear Panel (2)
7
358473 Nut, Push-In (2)
8
3400611 Screw,
Lid Switch
9
3953152 Shield, Pressure
Switch
10
3353948 Bracket, Lock
11
8054980 Switch, Lid
12
63554 Rivet (2)
13
355274 Screw, Lid Hinge
Mounting (4)
14
21097 Pad, Lid Hinge (2)
15
8524784 Hinge, Lid (L.H.)
16
54583 Hinge, Lid (R.H.)
17
19119 Bumper, Lid Hinge
18
21258 Bearing, Lid
Hinge (2)
19
8316257 Lid
20
387371 Plug Lock
21
3353812 Locator (4)
22
356908 Bumper, Lid
23
718258 Screw (4)
24 W10004930 Clip, U-Bend (2)
25
3353993 Screw (2)
26
356907 Rivet, Plastic
27
3393258 Screw, Panel
Mtg. (2)
28
3976380 Side Panel (RH)
29
3976382 Side Panel (LH)
30
3353949 Pin, Locator (2)
31
18776 Lock (2)
32
90406 Cage Nut
FOR ORDERING INFORMATION REFER TO PARTS PRICE LIST
3
W10114744
