Screw
Screw
Removable oven door(s)
The oven door(s) can be removed to change
optional oven door front(s) (if available).
NOTE: It is recommended not to remove the Self­
Cleaning Oven door (single/upper) unless you
are changing the optional oven door front. The
lower oven door (standard clean oven) can be
removed for cleaning. See “Cleaning tips" on
page 28.
AWARNING
Personal Injury Hazard
• Oven doors are heavy. Use both hands to
remove the oven doors.
• Grasp only the sides of the oven door. Do
not use any portion of the front frame or
trim for lifting.
Failure to properly grasp the oven door
could result in personal injury or product
damage.
To remove:
1. Open the door completely.
2. Remove the two screws just above the oven
door hinges.
3. Close door to the Broil Stop position (door will
be open about 6 inches).
4. Hold the door firmly on both sides and lift the
door up and out of the hinge slots to remove.
Set the door aside.
To replace:
1. Grasp door firmly on both sides. Slide the hinge
slot in the bottom of the door over the hinges.
Push the door down and in to replace.
2. Open the door slightly past the Broil Stop
position and push it down to make sure the door
is completely installed.
3. Open the door completely. Replace the two
oven door screws.
4. Close and open the door slowly to make sure it
is replaced properly.
NOTE: The inside of the Single/Upper Oven door
has a slot for the Oven Lock Lever. Do not replace
the Lower Oven door on the Upper Oven cavity, or
damage to the interior finish may result from the
Lock Lever hitting the door surface.
