Radio operations – Clarion ] DXZ715 User Manual

Page 7

DXZ715/HX-D10

Radio Operations

FM Reception

For enhanced FM performance the
tuner includes signal actuated stereo control,
Enhanced Multi AGC, Impulse noise reduction
curcuits and Multipath noise reduction circuits.

Changing the reception area

This unit is initially set to USA frequency intervals
of 10 kHz for AM and 200 kHz for FM. When using
it outside the USA, the frequency reception range
can be switched to the intervals below.

●

Setting the reception area

1. Press BND button

and select the desired

radio band (FM or AM).

2. While pressing DISP button

, each time you

press and hold the number “6” of the Preset
buttons

for 2 seconds or longer, the recep-

tion area switches from inside the USA to
outside the USA or from outside the USA to
inside the USA.

∗

Any station preset memories are lost when the

reception area is changed.

Listening to the radio

1. Press FUNCTION button

and select the

radio mode. The frequency is displayed.

2. Press BAND button

and select the radio

band. Each time the button is pressed, the radio
reception band changes in the following order:

FM1

➜

FM2

➜

FM3

➜

FM1...

3. Press the right or left side of SEARCH button

to tune in the desired station.

Tuning

There are 3 types of tuning mode available, seek
tuning, manual tuning and preset tuning.

Seek tuning

1. Press BAND button

and select the desired

band. (FM or AM)

∗

If “MANU” is lit in the display, press and hold
BAND button

for 1 second or longer.

“MANU” in the display goes off and seek tuning
is now available.

2. Press the right or left side of SEARCH button

to automatically seek a station.

When the right side of SEARCH button

pressed, the station is sought in the direction
of higher frequencies; if the left side of
SEARCH button

is pressed, the station is

sought in the direction of lower frequencies.

Manual tuning

There are 2 ways available: Quick tuning and step
tuning.
When you are in the step tuning mode, the fre-
quency changes one step at a time. In quick tun-
ing mode, you can quickly tune the desired fre-
quency.

1. Press BND button

and select the desired

band (FM or AM).

∗

If “MANU” is not lit in the display, press and
hold BND button

for 1 second or longer.

“MANU” is lit in the display and manual tuning
is now available.

2. Tune into a station.

●

Quick tuning:

Press and hold the right or left side of
SEARCH button

for 1 second or longer to

tune in a station.

●

Step tuning:

Press the right or left side of SEARCH button

to manually tune in a station.

Recalling a preset station

A total of 24 preset positions (6-FM1, 6-FM2, 6-
FM3, 6-AM) exists to store individual radio sta-
tions in memory. Pressing the corresponding pre-
set button recalls the stored radio frequency au-
tomatically.

1. Press BND button

and select the desired

band (FM or AM).

2. Press the corresponding Preset button

recall the stored station.

∗

Press and hold one of Preset buttons

for 2

seconds or longer to store that station into pre-
set memory.

Manual memory

1. Select the desired station with seek tuning,

manual tuning or preset tuning.

2. Press and hold one of Preset buttons

for 2

seconds or longer to store the current station
into preset memory.

Auto store

Auto store is a function for storing up to 6 sta-
tions that are automatically tuned in sequentially.
If 6 receivable stations cannot be received, a pre-
viously stored station remains unoverwritten at
the memory position.

1. Press BND button

and select the desired

band (FM or AM).

2. Press the SEARCH button

and select from

“TREB GAIN ”

➜

“TREB F 12K ”

➜

“TREB GAIN ”.

3. Turn the Rotary knob

(

clockwise or coun-

terclockwise as needed and adjust the gain
and the F (center frequency).

TREB GAIN : –6 to 6 (The factory default

setting is “0”)

TREB F :

8KHz/12KHz (The Factory
default setting is “12K”)

4. When the adjustment is complete, press A-M

button

several times until the function mode

is reached.

Adjusting the balance

1. Press A-M button

and select “BALANCE”.

2. Turning the Rotary knob

(

clockwise empha-

sizes the sound from the right speaker; turn-
ing it counterclockwise emphasizes the sound
from the left speaker.

∗

The factory default setting is “0”. (Adjustment
range: L13 to R13)

3. When the adjustment is complete, press A-M

button

several times until the function mode

is reached.

Adjusting the fader

1. Press A-M button

and select “FADER”.

2. Turning the Rotary knob

(

clockwise empha-

sizes the sound from the front speakers; turn-
ing it counterclockwise emphasizes the sound
from the rear speakers.

∗

The factory default setting is “0”. (Adjustment
range: F12 to R12)

3. When the adjustment is complete, press A-M

button

several times until the function mode

is reached.

Adjusting the Beat EQ

1. Press BEQ button

and select the Beat EQ

mode (1 to 3) to adjust.

2. Press A-M button

and select “BASS

BOOST or IMPACT or EXCITE”.

3. Turning the Rotary knob

(

clockwise adjusts

in the + direction; turning it counterclockwise
adjusts in the – direction.

∗

When BASS BOOST is selected, you can ad-

just the bass in the range of – 3 to 3.

∗

When IMPACT and EXCITE is selected, you can

adjust the bass and treble in the range of – 3 to 3.

Basic Operations

4. When the adjustment is complete, press A-M

button

several times until the function mode

is reached.

Turning on/off the loudness

The loudness effect emphasizes the bass and
treble to create a natural sound tone. When you
are listening to music at a low volume, it is rec-
ommended to use the loudness effect.

1. Press and hold LOUD button

for 1 second

or longer to turn on the loudness effect. When
the loudness effect is turned on, “LD” lights in
the display.

2. Press and hold LOUD button

for 1 second

or longer to turn off the loudness effect. “LD”
goes off in the display.

Note:
• When using a sold separately digital sound pro-

cessor (DPH910), a feature called auto loudness
is selected. This function is different from the loud-
ness effect. For further details on the auto loud-
ness feature, refer to the subsection “Output ad-
justment of auto loudness, subwoofer and
playback band” in section “AC Processer
Operations”.
