8
RADIO INSTALLATION
Engine
1. Install the servos as shown above.
Adjust the pushrods so that the servo arms
are centered.
2. Remove the screw that holds the fuel tank
brace and remove the brace.
Wrap your radio battery with 1/2” foam (not
included) and place it on the fuselage bottom
just behind the fuel tank.
Wrap your receiver in 1/2” foam (not includ-
ed) and place it in front of the servo tray.
Engine
Screw for fuel
tank brace
Screw for fuel
tank brace
3. Reinstall the fuel tank brace.
3. Find the switch hole precut in the side of the
fuselage and install the radio switch..
Engine
1. Using glass cleaner and a soft cloth, clean the
model surface thoroughly before applying
decals.
Cut the decal sheets apart in sections, as
needed.
Peel the backing off the decal and apply the
decal to the plane.
DECAL
