7
Caution:
Thread lock must be used where
ever any machine bolts are going into
any type of nuts. If you do not use
thread lock the bolts could become
loose and fall out in flight.
Place thread lock on each of the
bolts holding the motor mount to the
firewall. Make sure each bolt is tight
to the fire wall.
Note:
The Protégé 60 ARF was designed for any .60 size 2 stroke motor. We have set
the motor mounts to fit most .60’s. We are showing an OS.61 FX 2 stroke. If
your motor will not fit in the mounts then you will have to remove the motor
mounts and move them to fit you motor.
ENGINE INSTALLATION
1. The motor mounts are pre installed for an OS
61 FX.
Install you engine using the socket head
sheet metal screws.
2. Place the throttle push rod snap link on the
carburetor.
Slide the silicone keeper over the snap link.
3. Install the fuel lines to the engine.
Carburetor Fuel Line
Vent Line
