CAMCORP Blower Package with M-D Pneumatics Blower User Manual
Page 31
19
PARTS LIST - MODELS 4604, 4606, 4609, 4612
When ordering parts, use the item number shown, plus your model and serial number.
MODEL
LOBE TO END PLATES
INTERLOBE
GEAR END
DRIVE END
TIP-DOWEL
TIP-PORT
MININUM
4604
.004” - .008”
(.10 - .20)
.005” - .009”
(.13 - 23)
.007” - .011”
(.18 - .28)
.009” - .013”
(.23 - .33)
.008” - .012
(.20 - .30)
4606
.004” - .008”
(.10 - .20)
.006” - .010”
(.10 - 25)
.007” - .011”
(.18 - .28)
.009” - .013”
(.23 - .33)
.008” - .012
(.20 - .30)
4609
.004” - .008”
(.10 - .20)
.009”- .013”
(.23 - .33)
.007” - .011”
(.18 - .28)
.009” - .013”
(.23 - .33)
.008” - .012
(.20 - .30)
4612
.004” - .008”
(.10 - .20)
.012” - .016”
(.30 - .41)
.007” - .011”
(.18 - .28)
.009” - .013”
(.23 - .33)
.008” - .012
(.20 - .30)
LOBE TO CASING
ASSEMBLY CLEARANCES
Metric values (mm) are shown in parentheses ( )
All other values are in inches
ITEM DESCRIPTION
QTY
ITEM DESCRIPTION
QTY
1
Rotor, Drive
1
31
Drain Plug, Magnetic
2
2
Rotor, Driven
1
37
Breather
2
3
Housing
1
38
Port Flange (“D” suffix units only)
2
4
End Plate
2
39
Gasket (“D” suffix units only)
2
6
End Cover, Drive End
1
40 * Cap Screw (“D” suffix units only)
AR
7
End Cover, Gear End
1
41
Lockwasher (“D” suffix units only)
8
8
Timing Gear Set
1
50
Bearing, Cylindrical Roller
1
9
Bearing, Double Row Ball
2
58
Seal Ring
4
10
Bearing, Cylindrical Roller
1
62
Cap Screw
16
12
Lip Seal, Rotor Shaft
4
68
Spring Pin
1
13
Lip Seal, Drive Shaft
1
70
Oil Sight Gauge
2
14
Retainer Plate
4
80
Lockwasher
4
20
Oil Slinger
1
123
Wave Spring
2
22
Dowel Pin
4
126
Spring Pin
4
23
Key, Drive Shaft
1
174
Pipe Plug
2
24
Key, Gear
2
239
Sleeve
4
25
Washer
2
281
Spacer
1
26
Cap Screw
28
282
Wave Spring
3
27
Washer
1
304
Mounting Foot
AR
29
Cap Screw
2
307
Cap Screw
5
* Item 40 not used on model 4606D.
