Figure 6 - (Continued) INTERUNIT CABLE CONFIGURATIONS
Figure 6-5 -
Typical 6V VRLA
Dual Cable Connection
Figure 6-4 -
UPS12-100MR
0.5
DUAL CABLE
ASSEMBLY PART NO.
12466 2/0 FLEX CABLE
150-20496
0.5
CABLE ASSEMBLY PART NUMBER
32677 #6 FLEX CABLE
150-16601
