39 38
6-DISC CD CHANGER FOR CeNET
DCZ625
•
6-Disc Magazine
•
Plays CD-R and CD-RW Discs
• 8x Oversampling Digital Filter
• Horizontal or Vertical Mounting Capability
• Fiber Optical Digital Output
• CD Text and CD Titling
• CeNET
4/3/2-CHANNEL POWER AMPLIFIER
APX480M
• Watertight • Meets or Exceeds ASTM B117 (Salt/Fog
Exposure)
•
Meets or Exceeds ASTM D4329 (UV Exposure)
•
6.5” Polypropylene Woofer Cone
•
1” Titanium-Coated
Dome Tweeter • Sanoprene Rubber Surround • High-
Impact Centrix 814 Grille/Frame • Protected Magnet and
Rear Cone Design • Liquid Drainage Channel • Rubber
Insulated Tinsel Leads • Speaker Cable Support Tan
• Gold-Plated Speaker Terminals • 316 Stainless Steel
Mounting Hardware
•
Rubber Mounting Gasket
•
100-Watt Power Handling
6.5” Component Marine Speaker System
CM1635
• Watertight • Meets or Exceeds ASTM B117 (Salt/Fog
Exposure) • Meets or Exceeds ASTM D4329 (UV Exposure)
• 6.5” Polypropylene Woofer Cone • 1” Titanium-Coated
Dome Tweeter
•
Sanoprene Rubber Surround
•
High-Impact
Centrix 814 Grille/Frame
•
Protected Magnet and Rear
Cone Design • Liquid Drainage Channel • Rubber Insulated
Tinsel Leads • Speaker Cable Support Tan • Gold-Plated
Speaker Terminals • 316 Stainless Steel Mounting
Hardware • Rubber Mounting Gasket
• 100-Watt Power Handling
6.5” COAXIAL MARINE SPEAKER
CM1625
• Watertight
• Meets or Exceeds ASTM B117
•
Meets or Exceeds ASTM 04329
(UV Exposure)
• 10” Polypropylene Cone
• Sanoprene Rubber Surround
•
High-Impact Centrex 814 Grille
& Frame
• Protected Magnet and Rear-
Cone Design
• Liquid Drain Channel
• Rubber Insulated Tinsel Leads
•
Speaker Cable Support Tab
• Gold-Plated Speaker Terminals
• 316 Stainless Steel Mounting
Hardware
•
Rubber Mounting Gasket
• Optimized for Infinite Baffle
Application
•
350-Watt Power Handling
• Watertight • 1” Titanium Dome Tweeter
• Meets or Exceeds ASTM B117 (Salt/Fog
Exposure)
•
Meets or Exceeds ASTM
D4329 (UV Exposure)
•
7” Polypropylene
Woofer Cone • Flush and Surface Tweeter
Mounts • Integrated Passive Crossover
• Sanoprene Rubber Surround • High-
Impact Centrix 814 Grille/Frame
• Protected Magnet and Rear Cone Design
•
Liquid Drainage Channel
•
Rubber
Insulated Tinsel Leads
•
Speaker Cable
Support Tab • Gold-Plated Speaker
Terminals • 316 Stainless Steel Mounting
Hardware • Rubber Mounting Gasket
• 130-Watt Power Handling
7” COMPONENT MARINE
SPEAKER SYSTEM
CMCS7.1
7” COAXIAL MARINE SPEAKER
CMCX7.1
7” DUAL CONE MARINE
SPEAKER
CMDC7.1
SPORT SERIES 7”
COAXIAL MARINE SPEAKER
CMCX7.1s
• Watertight • 1” Titanium Dome Tweeter
• Meets or Exceeds ASTM B117 (Salt/Fog
Exposure)
•
Meets or Exceeds ASTM
D4329 (UV Exposure)
•
7” Polypropylene
Woofer Cone • Sanoprene Rubber Surround
• High-Impact Centrix 814 Grille/Frame
• Protected Magnet and Rear Cone Design
• Liquid Drainage Channel • Rubber
Insulated Tinsel Leads • Speaker Cable
Support Tan
•
Gold-Plated Speaker
Terminals
•
316 Stainless Steel Mounting
Hardware • Rubber Mounting Gasket
• 160-Watt Power Handling
• Watertight
• Meets or Exceeds ASTM B117
•
Meets or Exceeds ASTM 04329
(UV Exposure)
• 10” Polypropylene Cone
• Sanoprene Rubber Surround
•
High-Impact Centrex 814 Grille
& Frame
• Protected Magnet and Rear-
Cone Design
• Liquid Drain Channel
• Rubber Insulated Tinsel Leads
•
Speaker Cable Support Tab
• Gold-Plated Speaker Terminals
• 316 Stainless Steel Mounting
Hardware
•
Rubber Mounting Gasket
• Optimized for Infinite Baffle
Application
•
350-Watt Power Handling
• Watertight • Titanium Tweeter
• Meets or Exceeds ASTM B117 (Salt/Fog
Exposure)
•
Meets or Exceeds ASTM
D4329 (UV Exposure)
•
7” Polypropylene
Woofer Cone • 1” Titanium- Dome Tweeter
• Sanoprene Rubber Surround • High-
Impact Centrix 814 Grille/Frame
• Protected Magnet and Rear Cone Design
• Liquid Drainage Channel • Rubber
Insulated Tinsel Leads
•
Speaker Cable
Support Tab
•
Gold-Plated Speaker
Terminals • 316 Stainless Steel Mounting
Hardware • Rubber Mounting Gasket
• 160-Watt Power Handling
• Watertight • Meets or Exceeds ASTM
B117 (Salt/Fog Exposure) • Meets or
Exceeds ASTM D4329 (UV Exposure)
•
7” Dual Polypropylene Woofer Cone
• Sanoprene Rubber Surround
• High-Impact Centrix 814 Grille/Frame
• Protected Magnet and Rear Cone Design
• Liquid Drainage Channel • Rubber
Insulated Tinsel Leads • Speaker Cable
Support Tab
•
Gold-Plated Speaker
Terminals
•
316 Stainless Steel Mounting
Hardware • Rubber Mounting Gasket
• 120-Watt Power Handling
•
Watertight
•
Meets or Exceeds ASTM B117 (Salt/Fog
Exposure)
•
Meets or Exceeds ASTM D4329 (UV Exposure)
• 6.5” Dual Polypropylene Woofer Cone • Sanoprene
Rubber Surround • High-Impact Centrix 811 Grille/Frame
• Protected Magnet and Rear Cone Design
• Liquid Drainage Channel • Rubber Insulated Tinsel Leads
• Speaker Cable Support Tab • Gold-Plated Speaker
Terminals
•
316 Stainless Steel Mounting Hardware
•
Rubber Mounting Gasket
•
100-Watt Power Handling
6.5” DUAL CONE MARINE SPEAKER
CM1605
CM1605
CM1635
CM1625
CMCS7.1
CMCX7.1s
CMCX7.1
CMDC7.1
MARINE AUDIO
10” WATER-RESISTANT MARINE
SUBWOOFER
CMSW10.1
10” SPORT SERIES MARINE
SUBWOOFER
CMSW10.1s
•
Maximum 320-Watt Power Output
• Continuous 160-Watt Average Power Output
(80W x 2 Into 4 Ohms, 20Hz-20kHz @0.05% THD)
•
Typical 2-Ohm Stereo 125W x 2 @ 0.2% THD
• Typical Bridged Power 1kHz 250W x 1 @ 0.2% THD
• Bass Extender Control 0-15dB @ 45 kHz
• Adjustable 55Hz-550Hz, 12dB/oct. High- / Low-Pass
Crossover
• Mixed-Mode Operation
2/1-CHANNEL POWER AMPLIFIER
APX280M
•
Maximum 640-Watt Power
Output
• Continuous 320-Watt Average
Power Output (80W x 4 Into 4
Ohms, 20Hz-20kHz @.05%THD)
• Typical 2-Ohm Stereo 115W x 4
@ 0.2% THD
•
Bass Extender Control 0-15dB
@ 45 kHz
•
Adjustable 55Hz-550Hz,
12dB/oct. High- / Low-Pass
Crossover
•
Mixed-Mode Operation
• 4- / 3- / 2-Channel Operation
• MOS-FET Output Design
• Speaker Level Inputs
•
Double-Sided FR4 PC Board
