B1 B2 B3 B4 B5 B6 B7
50Hz 125Hz 315Hz 750Hz 2.2kHz 6kHz 16kHz
• Play/Pause Selector
• Repeat Play
• Random/Scan Play
• Track Search
•
Disc Selector
•
Software Controlled Setup
• Flush Mounting Bracket Included
33
CHANGERS/PROCESSORS
32
FM200
FM MODULATOR
EA1251B
CeNET iPod INTERFACE
• 2-Channel
RCA Audio Output
• On/Off Switch
• Volume Level Control
CCA329
C-BUS 16˝ FOOT
REPLACEMENT CHANGER
CABLE
CCA561
CeNET 16˝
REPLACEMENT CHANGER
CABLE
CCA520
CeNET 8˝ M/F EXTENSION
CABLE
CCA521
CeNET 20.5˝ M/F
EXTENSION
CAA397
6 DISC MAGAZINE
FOR DCZ625, DC625
CHANGERS
CAA355
6 DISC MAGAZINE FOR
CDC655TZ, CDC635,
XM655-RET CHANGERS
CCA519
CeNET Y ADAPTER
FOR MULTI-CHANGER CONNECTION
DCA005
16˝ FIBER OPTIC CABLE
2004 SOURCE UNIT SIDE
TO DVH940
DCA006
16˝ FIBER OPTIC CABLE
2001 SOURCE UNIT SIDE
TO DVH940
DCA007
16˝ FIBER OPTIC CABLE
2004 SOURCE UNIT SIDE
TO DPH910/DVS9755Z BOX
DCA008
5˝ FIBER OPTIC CABLE
2004 SOURCE UNIT SIDE
TO DVH940
Play Back CD Sound on Any FM Car Radio
The FMC250 controls a Clarion CD changer
and plays back the sound via your FM car
radio — no matter which brand. The FMC250
hideaway unit con-nects between your FM
radio antenna input and the car antenna.
Simply tune your radio anywhere from 87.7 to
89.9 MHz (0.2 MHz step 12- point) and listen
to superior Hi-Fi CD sound in full stereo from
the connected Clarion CD changer.
Compact for Installation Anywhere
The DCZ625 and DC625 like Clarion’s other
CD changers, are so compact that they will fit
almost anywhere in your car: in the boot, on
the rear parcel shelf, or hanging under the
dash. They say good things come in small
parcels — the DCZ625 and DC625 are just
such a parcels.
Accessories complete the system.
From steering wheel remotes to extra maga-
zines for your CD changer, Clarion has the
acces-sories to complete your dream system.
New 1/2 DIN Equalizer with 7 bands of adjustment,
and built-in highpass and low pass cr ossvers with
subwoofer level control
A versatile crossover with inputs for either a three way system,
or a two way system withfront and rear fader control.
A wired remotesubwoofer level control is included.
6-DISC CD CHANGER FOR C-BUS
DC625
• 6-Disc Magazine
• Plays CD-R and CD-RW Discs
• 8x Oversampling Digital Filter
• Horizontal or Vertical Mounting Capability
•
C-BUS
CD CHANGER CONTROLLER WITH
FM MODULATOR
FMC250
1/2 DIN GRAPHIC EQUALIZER/CROSSOVER
EQS 744
•
7-Band Graphic Equalizer
• Selectable Main & Aux. Inputs
• Subwoofer Level Control
• Selectable Subwoofer Low Pass
Frequency 60Hz or 90Hz
•
6-Channel/ 7-Volt RCA Line Level
Output
Take Control With Clarion’s 7-Band
Graphic Equalizer
Clarion’s reputation for creating high quality EQs
dates back to the dawn of the car audio industry.
Bottom line, we know how to put sound enthusiasts
in control of their sound system. The legacy continues
with the EQS744 7-band graphic equalizer, a unit
offering a high signal-to-noise ratio with its 7-volt
RCA output, as well as superior control with frequen-
cy adjustments in the 50kHz-to-16kHz range over
seven bands. This means users can get the most out
of their sound system, as well as the ability to con-
tour the sound output to their musical tastes. This is
especially important when utilizing an external audio
source, such as a portable DVD player, TV tuner or
VCR, through the AUX input.
6-DISC CD CHANGER FOR CeNET
DCZ625
• 6-Disc Magazine
• Plays CD-R and CD-RW Discs
• 8x Oversampling Digital Filter
• Horizontal or Vertical Mounting Capability
• Fiber Optical Digital Output
•
CD Text and CD Titling
•
CeNET
Accessories
FM Modulator FM Car Radio (any Model) FMC250 Display Unit
CD Changer (DC625)
FM Antenna
FM Modulator
87.7 to 89.9 MHz (0.2 MHz Step 12-Point)
Antenna Input
3-WAY ELECTRONIC CROSSOVER
MCD360
• 18 dB/oct. Slope
•
Front/Rear Subwoofer Level Control
•
Built-in Bass EQ
• Remote Subwoofer Level Control (included)
• Cross Frequency Multiplier
• 2/4/6-Channel Inputs / Separate F/R
Crossover
•
6-Channel Line Level Outputs
