5490
Remote Outdoor Sensor
MODEL
USER MANUAL
READ ALL INSTRUCTIONS BEFORE PROCEEDING
The Braeburn 5490 Remote Outdoor Sensor senses the
outdoor air temperature and transmits the information
to a compatible Braeburn thermostat. When the 5490
sensor has been installed, the thermostat can display
the outdoor temperature, limit the heat pump system,
and automatically limit humidification settings.
WARNING!
Important Information
• Read this manual thoroughly prior to installing remote outdoor sensor.
• The 5490 Remote Outdoor Sensor is not used to control
room temperature.
• Prior to finishing installation, refer to the Braeburn
®
thermostat
Installation Guide and test thermostat operation.
• This remote outdoor sensor should only be used as described in this
manual. Any other use is not recommended and will void the warranty.
INSTALLATION
NOTE:
When installing the remote outdoor sensor, be sure to locate
the remote outdoor sensor at least 3 feet from all exhaust fans. It should
be mounted on the north, east or west side of the building out of direct
sunlight and above the expected snow line. Incorrect temperature
control may result if these requirements are not met.
