1) When bolting on the poly hood, start on one
side and keep nuts loose until bolts on the
other side have been started.
2) After bolts on both sides have been
placed, tighten all four nuts and bolts.
ASSEMBLY INSTRUCTIONS
5
Locate Clip (8) as
shown in detail
(5) Hood
Support
Weldment
(4) Arm
Weldment
Clip Placement Detail
