Contents
iv
Installation and Upgrade Guide for Cisco Unified Videoconferencing 3545 PRI Gateway and 3545 Serial Gateway Release 5.5
OL-14912-01
Setting the IP Address 2-11
Changing the Configuration Tool Login Password 2-12
Upgrading Gateway Software 2-13
Connecting the Gateway to the Network 2-14
Connecting PRI Lines to the Gateway 2-14
Connecting Serial Lines to the Gateway 2-14
Serial Gateway Cable Connections and Pin-outs 2-15
Physical Description of DTE Cables 2-15
Physical Description of DCE Cables 2-19
Data Interface Cable Pin-out Configurations 2-21
Data Interface Pin Layouts 2-22
DB-25 Connector 2-24
Signaling Interface Cable Pin-out Configuration 2-25
Signaling Interface Pin Layout 2-26
Connecting the Gateway to a Power Source 2-27
Accessing the Gateway Administrator Interface 2-27
Registering the Online Help 2-28
Netscape Navigator Users 2-28
C H A P T E R
3 Using the Cisco Software Upgrade Utility 3-1
Introduction 3-1
Launching the Cisco Software Upgrade Utility 3-1
Upgrading Software 3-2
C H A P T E R
4 Cable Connections and Pin-outs 4-1
Unit RS-232 9-Pin Serial Port 4-1
9-Pin Serial Port Terminal Cable 4-2
RJ-45 8-Pin IP Network Port 4-2
Circuit Switch Network Port 4-3
ISDN Port 4-3
C H A P T E R
5 Technical Specifications 5-1
Technical Specifications Table 5-1
C H A P T E R
6 Safety 6-1
Electrical Safety 6-1
Grounding 6-1
