CT-S280

CITIZEN SYSTEMS AMERICA CORPORATION

Rev. 5/07

Specifications

Printing Method

Line thermal dot print method

Print Width

48mm/384 dots

Dot Density

8 (horizontal) X 8 (vertical) dots/mm (203 dpi)

Print Speed

80mm/sec.

Number of Columns

Font A: 32 columns; 12 x 24 dots horizontal and vertical
Font B: 42 columns; 9 x 24 dots
Font C: 48 columns; 8 x 16 dots

Character Size

Font A: 1.50 x 3.00mm, Font B: 1.13 x 3.00mm, Font C: 1.00 x 2.00mm

Character type

Alphanumeric, International, PC437, 850, 852, 857, 858, 860, 863, 864, 865,
866, WPC1252, Katakana, Thai code 18

User-defined Logo/Characters

User-defined characters and logos can be registered in flash memory.

Barcode Types

UPC-A/E, JAN (EAN) 13/8 columns, ITF, CODE 39, CODE 128, CODABAR,
CODE 93

Line Feed Pitch

4.23 mm (1/16 inch) User selectable

Paper Roll

Thermal paper roll: 58mm x 83mm OD
Paper thickness: 0.065 - 0.075mm

Interface

Serial (RS-232C compliant), Parallel (IEEE 1284 compliant), or USB

Input Buffer

4k bytes/45 bytes

Supply Voltage

DC 8.5V±5%

Power Consumption

Standby: Approx. 2W, Printing: Approx. 18W (Approx. 26W max.)

AC Adapter Specifications

Rated input: AC 100-240V, 50/60Hz
Rated output: DC 8.5V, 2.5A

Weight

Approx. 430g

Outside Dimensions (W x D x H)

106 x 170 x 116mm

Environment

Operation Temperature 5-40 C°, Humidity 10-85 RH% (no condensation)
Storage

Temperature -20 to 60 C°, Humidity 10-90 RH% (no condensation)

Reliability

Pulse Resistance: 1 x 108 pulses (printing rate 12.5%)
Wear Resistance: 50km (normal temperature/humidity with
