Antari HZ-350 User Manual

Page 8

If the value of channel A is set between 0 to 10, the unit is off.

While the value is set between 11 to 255, the unit is on.

Note: Once DMX cable is connected to the unit, then the LCD control panel, W-1

transmitter and HC-1 controller connected cannot be used.

CAUTION

Never drink haze fluid. If feel sick after ingesting in any case, call the

doctor immediately. If haze fluid comes in contact with skin or eyes,

rinse thoroughly with cold water.

- The fan located at the rear of the machine is set to stop 60 seconds after the output is

terminated for the purpose of radiating. Thus it is advised to power off the machine after the

termination of fan.

- If you have followed the above operation steps, and you still experience low output,

mechanical noise or no output at all, unplug the unit immediately from the mains. Check the

fluid level, the external fuse, the remote control connection, and the power cable from the

wall. If all of the above appears to be O.K., plug again. If the hazer is still not functional,

discontinue operating otherwise it may result in permanent damage to the unit. Return the

machine to your Antari dealer. Always drain tank before sending the unit.

DMX CONNECTOR PIN ASSIGNMENT

The machine provide 5 pin XLR connector for DMX connection. Diagram below indicate pin

assignment information

Function

Ground

Data-

Data+
