— 26 —
5.3 Manual Setting of Memory Switch
Memory switches can be set manually or by a command.
For manual setting, refer to the next page.
The function of each memory switch is shown in the following table.
(The
white-on-black characters are factory setting.)
Switch No. Setting 0 (OFF) 1 (ON)
Memory SW1-1 Power ON Info Valid Not send
SW1-2 Buffer Size 4k bytes 45 bytes
SW1-3 Busy Condition Full/Err Full
SW1-4 Receive Error Print ? No Print
SW1-5 CR mode Ignored LF
SW1-6 Reserved Fixed −
SW1-7 DSR Signal Invalid Valid
SW1-8 Init Signal Invalid Valid
Memory SW2-1 Reserved − Fixed
SW2-2 Auto Cutter Invalid Valid
SW2-3 Spool Print Invalid Valid
SW2-4 Full Col Print LineFeed WaitData
SW2-5 Resume aft PE Next Top
SW2-6 Reserved Fixed −
SW2-7 Reserved Fixed −
SW2-8 PNE Sensor Valid Invalid **
Memory SW3-1 Resum Cttr Err Valid Invalid
SW3-2 Reserved Fixed −
SW3-3 Parallel 31 Pin Valid Invalid
SW3-4 Reserved Fixed −
SW3-5 Reserved Fixed −
SW3-6 Reserved Fixed −
SW3-7 CBM1000 Mode Invalid Valid
SW3-8 Resum Open Err Close Command
Memory SW4-1 Reserved Fixed −
SW4-1*L Paper Length Setting Auto Measure Command
SW4-2 Reserved Fixed −
SW4-2*L Top of Form at Power ON Invalid Valid
SW4-3 Feed&Cut at TOF Invalid Valid
SW4-4 Reserved Fixed −
SW4-4*L Paper Select Thermal Roll BM.P/Lbl.P *
SW4-5 Reserved Fixed −
SW4-5*L Position Detect Black Mark Label
SW4-6 Reserved Fixed −
SW4-6*L Paper Change Invalid Valid
SW4-7 Reserved Fixed −
SW4-8 Partial only Invalid Valid
* When printing on label paper, adjust the layout so that right and left margins are 4 mm or more.
* The memory switch SW4-8 will be ignored for black mark paper.
* The memory switches SW2-8 and SW4-8 will be ignored for label.
