Overview of Cisco Network Modules
Cisco 3600 Series Routers
As shown in Figure 1-6, the port numbers for this router are:
• Slot 0, Ethernet interface 0—Ethernet 0/0
• Slot 0, Ethernet interface 1—Ethernet 0/1
• Slot 0, serial interface 0—Serial 0/0
• Slot 0, serial interface 1—Serial 0/1
• Slot 1, Ethernet interface 0—Ethernet 1/0
• Slot 1, Ethernet interface 1—Ethernet 1/1
• Slot 1, serial interface 0—Serial 1/0
• Slot 1, BRI interface 0—BRI 1/0
Note The 2-Ethernet 2-slot module described in this example provides
both an attachment unit interface (AUI) and a 10BaseT connector for
port 0. Only one of these connectors can be used at a time.
Voice Interface Numbering in Cisco 3600 Series Routers
Voice interfaces are numbered differently from WAN interfaces. Voice interfaces
are numbered as follows:
interface-type chassis-slot/voice module slot/voice port
If you have a four-channel voice network module installed in slot 1 of your router,
the voice interfaces are:
• Slot 1, voice network module slot 0, voice port 0—Voice 1/0/0 (closest to
chassis slot 0)
• Slot 1, voice network module slot 0, voice port 1—Voice 1/0/1
• Slot 1, voice network module slot 1, voice port 0—Voice 1/1/0
• Slot 1, voice network module slot 1, voice port 1—Voice 1/1/1 (farthest from
chassis slot 0)
