VII. TROUBLESHOOTING
Staus indicators are as follows:
FOR DEVICENET
LED Network Status (NS) Module Status (MS)
Off Not on-line or no power to the system. Module not powered
Green On-line, one or more connections established Normal Operation
Green Flashing On-line, no connections established Auto-baud in progress
Red Critical link failure Unrecoverable fault detected
Red Flashing Connection timeout Recoverable fault detected
Alternating Red/Green Flashing Self-test in progress Self-test in progress
FOR ETHERNET/IP
LED Network Status (NS) Module Status (MS)
Off Not on-line or no power to the system. Module not powered
Green On-line, one or more connections established Normal Operation
Green Flashing On-line, no connections established No connection
Red Duplicate IP address detected Unrecoverable fault detected
Red Flashing Connection timeout Recoverable fault detected
Alternating Red/Green Flashing Self-test in progress Self-test in progress
LED Network Status (LA) Module Status (RA)
Off Not on-line or no power to the system. 10 Mps operation
Green On-line, one or more connections established 100 Mps operation
Green Flashing RX/TX activity NA
Red NA NA
Red Flashing NA NA
Alternating Red/Green Flashing Self-test in progress Self-test in progress
FOR PROFIBUS DP
There is a single LED on the Profibus Module labeled D3.
LED Status
Off Module not powered
Green Node is in Data Exchange mode
Green Flashing Node in Clear mode
Red Error in initializing of module
Red Flashing Error in configuration of module
Alternating Red/Green Self-test in progress
