TapWatch Software Installation
05855E
16
2.5 Connecting to RDL8500 or RF Gateway
Connecting to a traditional TapWatch submetering network using the RDL8500
remote data logger and an RF gateway is covered in the RDL8500 Remote
Data Logger Installation Instructions included with the RDL8500. However, a
computer running TapWatch 3 software can also be directly connected to
either an RDL8500 or an RF gateway for purposes of maintenance or
troubleshooting.
2.5.1 Directly Connecting to an RDL8500
The computer running TapWatch 3 software can be directly connected to an
RDL8500 using the RDL8500 ethernet port, shown below.
Figure 2-3 RDL8500 Ethernet Port
2.5.2 Directly Connecting to an RF gateway
The computer running TapWatch 3 software can be directly connected to an
RF gateway using the Inovonics serial and power cable:
• http://www.inovonics.com/ACC643.aspx
Ethernet Port
