Holtgreven Above Ground Motor Truck Scale - Manual (Page 4)

G. Set side-to-side bumper blocks into place opposite corners of the scale.
H. If needed shift all stands to align the links. If you do not have equal pressure on
the cells you may need to shim under the stand. Recommend at least a 9” square plate. On
the concrete deck models adjust leveling bolts to match top of approach and to make sure
there is equal pressure on all cells.
I. Drill and set ¾” x 7” anchor bolts two per stand plus two for each of
the side to side bumper blocks.
J. Once everything has been leveled and shifted into place. Use a non-shrink grout
under each of the load cells stands. (Concrete deck models)
K. Adjust the Bumper bolts to minimum 1/8” and a max of ¼” on all four
corners of the scale Total of eight bumpers per scale.
